Description
SPECIFICATIONS:
GENERAL SPECIFICATIONS |
||
Platform |
Boxed Processor |
|
Product Family |
AMD Ryzen™ Processors |
|
Product Line |
AMD Ryzen™ 5 5000 G-Series Desktop Processors with Radeon™ Graphics |
|
# of CPU Cores |
6 |
|
Multithreading (SMT) |
Yes |
|
# of Threads |
12 |
|
Max. Boost Clock |
Up to 4.6GHz |
|
Base Clock |
3.6GHz |
|
L1 Cache |
384KB |
|
L2 Cache |
3MB |
|
L3 Cache |
16MB |
|
Default TDP |
65W |
|
AMD Configurable TDP (cTDP) |
45-65W |
|
Processor Technology for CPU Cores |
TSMC 7nm FinFET |
|
CPU Compute Die (CCD) Size |
180mm² |
|
Package Die Count |
1 |
|
Unlocked for Overclocking |
Yes |
|
CPU Socket |
AM4 |
|
Thermal Solution (PIB) |
AMD Wraith Stealth |
|
Thermal Solution (MPK) |
AMD Wraith Stealth |
|
Max. Operating Temperature (Tjmax) |
95°C |
|
*OS Support |
Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. |
|
CONNECTIVITY |
||
PCI Express® Version |
PCIe® 3.0 |
|
NVMe Support |
Boot, RAID0, RAID1, RAID10 |
|
System Memory Type |
DDR4 |
|
Memory Channels |
2 |
|
Max. Memory |
128GB |
|
System Memory Subtype |
UDIMM |
|
System Memory Specification |
Up to 3200MT/s |
|
Max Memory Speed |
2x1R 2x2R 4x1R 4x2R |
DDR4-3200 DDR4-3200 DDR4-2933 DDR4-2667 |
GRAPHICS CAPABILITIES |
||
Integrated Graphics |
Yes |
|
Graphics Model |
Radeon™ Graphics |
|
Graphics Core Count |
7 |
|
Graphics Frequency |
1900 MHz |
|
