Description
SPECIFICATIONS:
Family |
Ryzen Threadripper Pro |
Series |
Ryzen Threadripper Pro 7000 WX-Series |
Form Factor |
Desktops |
Number of CPU Cores |
96 |
Number of Threads |
192 |
Max. Boost Clock |
Up to 5.1 GHz (Max boost for AMD processors is the maximum frequency achievable by a single core on the processor running a bursty single-threaded workload. Max boost will vary based on several factors, including, but not limited to: thermal paste; system cooling; motherboard design and BIOS; the latest AMD chipset driver; and the latest OS updates. GD-150.) |
Base Clock |
2.5 GHz (Represents the average effective base frequency of all cores.) |
L2 Cache |
96 MB |
L3 Cache |
384 MB |
Default TDP |
350 W |
L1 Cache |
6144 KB |
Processor Technology for CPU Cores |
TSMC 5 nm FinFET |
Unlocked for Overclocking |
Yes (AMD`s product warranty does not cover damages caused by overclocking, even when overclocking is enabled via AMD hardware and / or software. GD-26.) |
CPU Socket |
sTR5 |
Thermal Solution (PIB) |
Not Included |
Max. Operating Temperature (Tjmax) |
95°C |
OS Support |
Windows 11 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
PCI Express® Version |
PCIe® 5.0 |
Memory Type |
DDR5 |
Memory Channels |
8 |
System Memory |
Up to 5200 MT/s |
Graphics Model |
Discrete Graphics Card Required |
Supported Technologies |
AMD EXPO™ Technology , AMD PRO technologies , AMD Ryzen™ Technologies |
