Description
SPECIFICATIONS:
MAIN SPEC |
|
Dimensions |
484 x 239 x 502 mm (DWH) |
Form Factor |
Mid Tower |
Materials |
Steel + Plastic + Wood |
Mainboard Support |
E-ATX (?330mm), ATX, Micro-ATX, ITX |
Front Access & Controls |
Power, Reset, USB 3.0 x 2, Type-C 10Gbps x 1, Headphone/Mic Combo Jack |
Side Panel |
Sound Dampening Side Panel (Both Sides) |
DRIVE BAYS |
|
Expansion Slots |
7 |
3.5" /2.5" |
2 / 2 |
2.5" |
1 |
FAN SUPPORT |
|
Front |
3 x 120mm / 3 x 140mm |
Top |
3 x 120mm / 2 x 140mm |
Power Supply Shroud |
2 x 120mm / 2 x 140mm |
Rear |
1 x 120mm / 1 x 140mm |
Included Fan(s) |
3 x 120mm PWM fans in front + 1 x 120mm PWM Reverse fan on PSU shroud + 1 x 140mm PWM fan in rear |
RADIATOR SUPPORT |
|
Front |
120 / 140 / 240 / 280 / 360 / 420mm |
Top |
120 / 140 / 240 / 280 / 360mm |
Rear |
120 / 140mm |
CLEARANCE |
|
Max GPU Length |
? 408mm |
Max CPU Cooler Height |
? 180mm |
Max PSU Length |
(Include cable) ? 235mm (with HDD) |
MISCELLANEOUS |
|
Dust Filter |
Bottom |
Net Weight |
8.8 Kg |
Gross Weight |
10.3 Kg |
