Description
SPECIFICATIONS:
MAIN SPEC |
|
Dimensions |
530 x 245 x 545 mm (DWH) |
Form Factor |
Full Tower |
Materials |
Steel + Plastic + Glass + Wood |
Mainboard Support |
E-ATX (?285mm), ATX, Micro-ATX, ITX |
Front Access & Controls |
Power, Reset, USB 3.0 x 2, Type-C 10Gbps x 1, Headphone/Mic Combo Jack, Temp. Display Switch x 1 |
Side Panel |
4mm Tempered Glass |
DRIVE BAYS |
|
Expansion Slots |
8 |
3.5" /2.5" |
4/4 |
2.5" |
2 |
FAN SUPPORT |
|
Front |
3 x 120mm / 3 x 140mm |
Top |
3 x 120mm / 3 x 140mm |
Power Supply Shroud |
3 x 120mm |
Bottom |
2 x 120mm / 2 x 140mm |
Rear |
1 x 120mm / 1 x 140mm |
Included Fan(s) |
3 x 140mm Tranquil PWM fans in front + 2 x 120mm P12R PWM reverse fans on PSU shroud + 1 x 140mm Tranquil PWM fan in rear |
RADIATOR SUPPORT |
|
Front |
120 / 140 / 240 / 280 / 360 / 420mm |
Top |
120 / 140 / 240 / 280 / 360 / 420mm |
Power Supply Shroud |
120 / 240 / 360mm |
Bottom |
120 / 240mm |
Rear |
120 / 140mm |
CLEARANCE |
|
Max GPU Length |
? 455mm |
Max CPU Cooler Height |
? 190mm |
Max PSU Length |
(Include cable) ? 180/300mm (with HDD) (Include cable) ? 470mm (without HDD) (Not Include cable) ? 180mm (Side Mount) |
MISCELLANEOUS |
|
Dust Filter |
Bottom |
Net Weight |
13.60 Kg |
Gross Weight |
16.65 Kg |
