Description
SPECIFICATIONS:
Model Name |
P12R ARGB / P12R ARGB White |
Fan Type |
ARGB PWM Fan |
Dimensions |
120 x 120 x 25 mm |
Bearing Type |
Hydraulic Bearing |
Fan Speed |
600±100~1500±150 RPM |
Airflow |
55.31~61.46 CFM (max.) |
Air Pressure |
0.87~1.07 mmH₂O (max.) |
Fan Noise Level |
14.2~29.5 dB(A) |
Lifespan |
30,000 hours / 40℃ | 40,000 hours / 25℃ |
Connector |
FAN: 4-pin | LED: 3-pin |
Rated Voltage |
FAN: DC 12 V | LED: DC 5 V |
Operation Voltage |
FAN: DC 7.0-13.8 V |
Rated Current |
FAN: 0.15 A (0.22A (max.)) | LED: 0.3 A |
