Description
SPECIFICATIONS:
Panel |
23.8" (Fast IPS) |
Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
Brightness (typical) |
300 cd/m² |
Contrast Ratio |
1000 : 1 (Typical) 80 Million : 1 (DCR) |
Response Time |
0.3ms (MPRT) / 1ms (GtG) |
Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
Color Gamut |
sRGB 127% (CIE1931) / DCI-P3 94% (CIE1976) |
Color Accuracy |
Delta E < 2 |
Optimum Resolution |
1920 × 1080 @ 200Hz – DisplayPort, HDMI; 1920 × 1080 @ 240Hz (OC) – DisplayPort, HDMI |
Display Colors |
16.7 Million |
Signal Input |
HDMI 2.0 × 1, DisplayPort 1.4 × 1 |
HDCP Version |
HDMI: 2.2, DisplayPort: 2.2 |
USB Hub |
no |
Power Supply |
External 12VDC, 2.5A |
Power Consumption (typical) |
30W |
Speakers |
no |
Line in & Earphone |
Earphone |
Wall-Mount |
100mm × 100mm |
Adjustable Stand |
Tilt: -5° ~ 20° |
Product without Stand (mm) |
320.8 (H) × 539.7 (W) × 51.1 (D) |
Product with Stand (mm) |
433.3 (H) × 539.7 (W) × 196.2 (D) |
Packaging (mm) |
396 (H) × 603 (W) × 130 (D) |
Product without Stand (kg) |
2.93 |
Product with Stand (kg) |
3.30 |
Product with Packaging (kg) |
4.27 |
Cabinet Color |
Black & Red |
Regulatory Approvals |
BSMI / CE / RoHS |
What's in the box |
DP Cable 1.5m × 1 |
