Description
SPECIFICATIONS:
Panel |
23.8" / IPS |
Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
Brightness (typical) |
250 cd/m² |
Contrast Ratio |
1000 : 1 (typical) / MEGA DCR |
Response Time |
8ms GtG (bw) |
Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
Color Gamut |
NTSC 99% (CIE1976) / sRGB 107% (CIE1931) |
Optimum Resolution |
1920 × 1080 @ 100Hz – HDMI; 1920 × 1080 @ 75Hz – VGA |
Display Colors |
16.7 Million |
Signal Input |
VGA × 1, HDMI 1.4 × 1 |
USB Hub |
No |
Power Supply |
External 12VDC, 2.0A |
Power Consumption (typical) |
22W |
Speakers |
No |
Line in & Earphone |
No |
Wall-Mount |
75mm x 75mm |
Adjustable Stand |
Tilt: - 5° ~ 20° |
Product without Stand (mm) |
322.1 (H) × 540.5 (W) × 36.0 (D) |
Product with Stand (mm) |
419.9 (H) × 540.5 (W) × 185.2 (D) |
Packaging (mm) |
395 (H) × 615 (W) × 110 (D) |
Product without Stand (kg) |
2.45 |
Product with Stand (kg) |
2.8 |
Product with Packaging (kg) |
3.8 |
Cabinet Color |
Black |
Regulatory Approvals |
CE / RoHS |
What's in the box |
HDMI Cable 1.5m × 1 |
