Description
SPECIFICATIONS:
Panel |
23.8" / IPS |
Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
Brightness (typical) |
300 cd/m² |
Contrast Ratio |
1300 : 1 (typical) 20 Million : 1 (DCR) |
Response Time |
4ms (GtG) |
Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
Color Gamut |
NTSC 104% (CIE1976) / sRGB 120% (CIE1931) |
Optimum Resolution |
1920 × 1080 @ 75Hz – DisplayPort 1.2, HDMI 1.4; 1920 × 1080 @ 60Hz – VGA |
Display Colors |
16.7 Million |
Signal Input |
HDMI 1.4 × 1, DisplayPort 1.2 × 1, VGA x 1 |
USB Hub |
no |
Power Supply |
Internal 100 - 240V ～ 1.5A, 50 / 60Hz |
Power Consumption (typical) |
18W |
Speakers |
2W × 2 |
Line in & Earphone |
Line In × 1, Earphone × 1 |
Wall-Mount |
100mm × 100mm |
Adjustable Stand |
Height adjustment: 150mm, Pivot: —90° ~ 90°, Swivel: 175° ± 5°, Tilt: —5° ~ 35° |
Product without Stand (mm) |
326.4 (H) × 540.0 (W) × 50.7 (D) |
Product with Stand (mm) |
386 ~ 503.6 (H) × 540.0 (W) × 200.1 (D) |
Packaging (mm) |
519 (H) × 613 (W) × 162 (D) |
Product without Stand (kg) |
2.63 |
Product with Stand (kg) |
4.45 |
Product with Packaging (kg) |
7.14 |
Cabinet Color |
Black |
Regulatory Approvals |
CE / FCC / TCO / EPA |
What's in the box |
HDMI Cable 1.8m × 1, DP Cable 1.8m × 1 |
