Description
SPECIFICATIONS:
I/O Ports |
1 x RJ-45 (Gigabit) port 2 x USB 3.2 Gen1 Type-A ports (5Gbps) 1 x 3.5mm audio combo jack 1 x USB 3.2 Gen2 Type-A port (10Gbps/5.0V2.4A) 1 x USB 3.2 Gen2 Type-C® port (10Gbps/5.0V 3.0A) 1 x SD card reader 1 x USB 3.2 Gen2 Type-C® port (DP1.4 only) 1 x HDMI™ 2.0 port 1 x DisplayPort 1.4 port 1x Kensington lock 1x Power button with indicator LED 1x DC jack(4.5 phi) |
Video Resolution |
HDMI Single Ext. Output: 3840×2160@60Hz Display Port Single Ext. Output: 3840×2160@60Hz USB-C Single Ext. Output: 3840×2160@60Hz |
OS Support |
Windows® 10 or above Mac OS 13 or later |
Power Adapter |
150W DC20.0V / 7.5A |
Secutiry |
Kensington lock |
Cable Length |
65cm |
Color |
Black |
Weight |
Dock:514g±5g Stand:95g±5g |
Dimensions |
160 x 80 x 32 mm |
Material |
Plastic, Metal |
Package Contents |
ASUS Triple Display USB-C Dock, docking stand, 150W adapter, power cord, user manual, warranty card |
Power button |
For ExperBook B series, One key operation (Press the power-button to wake up your laptop with multiple monitors during standby mode). For Other Windows Notebook (ASUS and Non-ASUS), Press the power-button can turn on/off LED and open/shot down DC300’sdisplay signal. |
Indicator LEDs |
For ExperBook B series, Please refer manual for "Indicator LEDs" actions. |
