Description
SPECIFICATIONS:
CPU |
|
CPU Model |
Realtek RTD1619B |
CPU Architecture |
ARM64 64-bit |
CPU Frequency |
Quad-Core 1.7GHz |
MEMORY |
|
Memory |
2GB DDR4 |
Memory Expandable up to |
not expandable |
Flash Memory |
8GB eMMC |
STORAGE |
|
Drive Bays |
4 |
Compatible Drive Type |
3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD |
Maximum Drive Bays with Expansion Unit |
16 |
Supports Hot Swappable Drives |
✓ |
EXTERNAL PORTS |
|
Expansion |
3x USB 3.2 Gen 1 |
Network |
1x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
Multimedia Output |
N/A |
OTHERS |
|
System Fan |
1x 120mm |
Power Supply Unit / Adapter |
90W x1 |
Input Power Voltage |
100V to 240V AC |
Certification |
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC |
OPERATION |
|
Power Consumption |
25.1W (Operation) 8.4W (Disk Hibernation); |
Noise Level |
19.7dB (HDD idle) |
Operation Temperature |
0°C~40°C (32°F~104°F) |
Storage Temperature |
-20°C~70°C (-4°F~158°F) |
Humidity |
5% to 95% RH |
SOFTWARE |
|
Supported OS |
Windows 10, 11, Server 2016, Server 2019, Server 2022 macOS UNIX, Linux, and BSD |
Supported Languages |
Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česk, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย |
Supported Browsers |
Firefox Chrome Safari Microsoft Edge |
SIZE AND WEIGHT |
|
Size |
170(H) x 174(W) x 230(D) mm |
Weight |
2.2 kg / 4.85 lbs |
PACKAGE |
|
Package Weight |
3.6 kg / 7.94 lbs |
Package Size |
237(H) x214(W) x323(D) mm |
Package Contents |
AS3304T v2 Unit x1 Quick Installation Guide AC Power Cord x1 AC Power Adapter x1 RJ-45 LAN Cable(Cat 5e) x1 Flat Head Screw (for 2.5" HDD) x16 Power Cord Bracket |
