Description
SPECIFICATIONS:
CPU |
|
CPU Model |
Intel ATOM C3538 |
CPU Architecture |
x64 64-bit |
CPU Frequency |
Quad-Core 2.1GHz |
MEMORY |
|
Memory |
8GB SO-DIMM DDR4 |
Memory Module Pre-installed |
8GB (1x 8GB) |
Total Memory Slots |
2 |
Memory Expandable up to |
64GB (2x 32GB) Support mixed capacity |
Flash Memory |
4GB eMMC |
STORAGE |
|
Drive Bays |
8 |
M.2 Drive Slots |
2 |
Compatible Drive Type |
3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 2280 NVMe M.2 2280 SATA 3 M.2 2260 SATA 3 M.2 2242 SATA 3 |
M.2 PCIe Interface |
PCIe 3.0 x2 |
Maximum Drive Bays with Expansion Unit |
16 |
Supports Hot Swappable Drives |
✓ |
EXTERNAL PORTS |
|
Expansion |
2x USB 3.2 Gen 1 |
Network |
2x 10 Gigabit Ethernet(10G/1G) 2x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
Multimedia Output |
N/A |
OTHERS |
|
System Fan |
2x 120mm |
LCD Panel |
✓ |
Power Supply Unit / Adapter |
250W x1 |
Input Power Voltage |
100V to 240V AC |
Certification |
FCC, CE, VCCI, BSMI, C-TICK |
OPERATION |
|
Power Consumption |
66.9W (Operation); |
Noise Level |
22dB (HDD idle) |
Operation Temperature |
0°C~40°C (32°F~104°F) |
Storage Temperature |
-20°C~70°C (-4°F~158°F) |
Humidity |
5% to 95% RH |
SIZE AND WEIGHT |
|
Size |
215.5(H) x 293(W) x 230(D) mm |
Weight |
6.2 (kg) / 13.67 (lb) |
SOFTWARE |
|
Supported OS |
Windows 10, 11, Server 2016, Server 2019, Server 2022 macOS UNIX, Linux, and BSD |
Supported Languages |
Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česk, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย |
Supported Browsers |
Firefox Chrome Safari Microsoft Edge |
PACKAGE |
|
Package Weight |
7.5 kg / 16.53 lbs |
Package Size |
340 (H) x 380 (W) x 324 (D) mm |
Package Contents |
LOCKERSTOR 8 (AS6508T) Unit x1 Quick Installation Guide AC Power Cord x1 RJ-45 LAN Cable(Cat 5e) x2 10GbE LAN Cable(Cat 6a) x2 Flat Head Screw (for 3.5" HDD) x32 Flat Head Screw (for 2.5" HDD) x32 M.2 thumbscrews x2 |
