Description
SPECIFICATIONS:
CPU |
|
CPU Model |
Intel Celeron N5105 |
CPU Architecture |
x64 64-bit |
CPU Frequency |
Quad-Core 2.0GHz (burst up 2.90 GHz) |
MEMORY |
|
Memory |
4GB SO-DIMM DDR4 |
Memory Module Pre-installed |
4GB (1x 4GB) |
Total Memory Slots |
2 |
Memory Expandable up to |
16GB (2x 8GB) Support mixed capacity |
Flash Memory |
8GB eMMC |
STORAGE |
|
Drive Bays |
4 |
M.2 Drive Slots |
4 |
Compatible Drive Type |
3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 2280 NVMe |
M.2 PCIe Interface |
PCIe 3.0 x1 |
Maximum Drive Bays with |
12 |
Supports Hot Swappable Drives |
✓ |
EXTERNAL PORTS |
|
Expansion |
2x USB 3.2 Gen 2 (10Gbps) |
Network |
2x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
PCIe Expansion Slots |
1x for optional expansion 10 GbE card |
Multimedia Output |
1x HDMI 2.0b |
OTHERS |
|
System Fan |
1x 120mm |
LCD Panel |
✓ |
Infrared Receiver |
✓ |
Power Supply Unit / Adapter |
90W x1 |
Input Power Voltage |
100V to 240V AC |
Certification |
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA |
OPERATION |
|
Power Consumption |
35 W (Operation); |
Noise Level |
17.6dB (HDD idle) |
Operation Temperature |
0°C~40°C (32°F~104°F) |
Storage Temperature |
-20°C~70°C (-4°F~158°F) |
Humidity |
5% to 95% RH |
Size |
185.5(H) x 170(W) x 230(D) mm |
Weight |
2.94 kg / 6.48 lb |
SOFTWARE |
|
Supported OS |
Windows 10, 11, Server 2016, Server 2019, Server 2022 macOS UNIX, Linux, and BSD |
Supported Languages |
Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česk, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย |
Supported Browsers |
Firefox Chrome Safari Microsoft Edge |
PACKAGE |
|
Package Weight |
4.36 kg / 9.64 lbs |
Package Size |
324(H) x300(W) x240(D) mm |
Package Contents |
AS6704T Unit x1 Quick Installation Guide AC Power Cord x1 AC Power Adapter x1 RJ-45 LAN Cable(Cat 5e) x2 Flat Head Screw (for 3.5" HDD) x16 Flat Head Screw (for 2.5" HDD) x16 Power Cord Bracket |
