Description
SPECIFICATIONS:
GENERAL |
|
Type |
Powered Bluetooth aptX speaker system |
Amplifier Type |
Class AB |
Power Output |
60 W peak power total (15 W RMS / 30 W peak per channel), AES |
Drivers |
2.75” aramid fiber woofers 0.75“ Silk dome tweeters |
Inputs |
3.5 mm stereo mini-jack, RCA L/R, USB, Bluetooth |
Outputs |
RCA variable line-out |
Input Voltages |
100-240 V 50/60 Hz auto-switching |
SNR |
>95 dB (typical A-weighted) |
THD+N |
<0.05% at all power settings |
Crosstalk |
<50 dB |
Frequency Response |
65 Hz-22 kHz ±2.0 dB |
Input Impedence |
10K ohms unbalanced |
Protection |
Output current limiting, thermal over-temperature, power on/off transient protection |
Power Consumption |
Idle: 10W |
BLUETOOTH |
|
Internal BT Receiver |
Qualcomm QCC 3031/3034 |
Input Bit Depth |
16 bit |
Bluetooth Receiver Type |
Bluetooth 5.0 |
Supported Codecs |
aptX, AAC, SBC |
Wireless Operation Range |
Up to 100 ft (30 m) typical |
Input Data Rate |
Determined by Bluetooth |
Wireless Latency |
~30 milliseconds (ms) |
USB |
|
Connector Type |
Micro-USB |
USB Device Class |
type 1.1 and above |
Input Bit Depth |
up to 16 bit native |
Input Sample Rate |
up to 48 kHz native. |
WEIGHTS AND MEASURES |
|
Dimensions (HWD) |
Each speaker - 6" (15.2 cm) x 4" (10.2 cm) x 5.25" (13.3 cm) |
Weight |
Left (active) - 3.6 lb (1.6 kg) Right (passive) - 3.2 lb (1.4 kg) |
ENVIRONMENTAL REQUIREMENTS |
|
Operating temperature |
32 degrees F to 95 degrees F |
Non-operating temperature |
-4 degrees F to 113 degrees F |
Relative humidity |
5% to 95% non-condensing |
PACKAGE CONTENTS |
|
What’s in the box |
A2+ Home Music System w/ Bluetooth aptX powered (left) speaker A2+ Home Music System w/ Bluetooth aptX passive (right) speaker 1 x Speaker wire (16AWG) 1 x USB cable 1 x Power supply w/ detachable AC cord 1 x Mini-jack audio cable 2 x Microfiber speaker bag 1 x Microfiber cable bag 1 x Microfiber power supply bag 1 x Setup guide |
