Description
SPECIFICATIONS:
GENERAL SPECIFICATIONS |
|
Type |
Powered Bluetooth aptX HD speaker system |
Amplifier Type |
Class AB |
Power Output |
120 W peak power total (30 W RMS / 60 W peak per channel), AES |
Drivers |
4″ aramid fibre woofers 0.75″ silk dome tweeters |
Inputs |
3.5 mm stereo mini-jack, USB, RCA L/R, Bluetooth |
Outputs |
RCA variable line-out, 3.5 mm mini-jack headphone out |
Input Voltages |
110-240 V 50/60 Hz auto-switching |
SNR |
>95 dB (typical A-weighted) |
THD+N |
<0.05% at all power settings |
Crosstalk |
<50 dB |
Frequency Response |
60 Hz-22 kHz ±1.5 dB |
Input Impedance |
5K ohms unbalanced |
Protection |
Output current limiting, thermal over-temperature, power on/off transient protection |
Power Consumption |
Idle: 10W |
BLUETOOTH SPECIFICATIONS |
|
Input Bit Depth |
24 bit (padded) |
Bluetooth Receiver Type |
Bluetooth 5.0 |
Supported Codecs |
aptX HD, aptX, AAC, SBC |
Wireless Operation Range |
Up to 100 ft (30 m) typical |
Input Data Rate |
Determined by Bluetooth |
Wireless Latency |
~30 milliseconds (ms) |
USB SPECIFICATIONS |
|
Connector Type |
Micro-USB |
USB Device Class |
USB 1.1 or above |
Input Bit Depth |
24 bit (padded) |
Input Sample Rate |
44.1 kHz/48 kHz |
HEADPHONE AMP SPECIFICATIONS |
|
Headphone Amp Type |
OPA2134 |
Full-scale Headphone Output Level |
2.0 V RMS |
Output Impedance |
2 ohms |
Recommended Headphone Impedance Level |
10 ohms to 10K ohms |
WEIGHTS AND MEASURES |
|
Dimensions (HWD) |
Each speaker – 9″(23 cm) x 5.5″ (14 cm) x 6.5″ (16.5 cm) |
Weight |
Left (active) – 7.2 lb (3.3 kg) Right (passive) – 5.4 lb (2.4 kg) |
Total Shipping Weight |
15 lb (6.8 kg) |
Shipping Box Dimensions (LWH) |
20″ (51 cm) x 13″ (33 cm) x 15.5″ (39 cm) |
ENVIRONMENTAL REQUIREMENTS |
|
Operating temperature: |
32 degrees F to 95 degrees F |
Non-operating temperature: |
-4 degrees F to 113 degrees F |
Relative humidity: |
5% to 95% non-condensing |
