Description
SPECIFICATIONS:
GENERAL |
|
Color |
White |
Motherboard compatibility |
E-ATX / XL-ATX / ATX / M-ATX / Mini-ATX |
Case size excl. stands (L x W x H), (mm) |
604 x 254 x 539 |
Case size incl. stands (L x W x H), (mm) |
604 x 275 x 569 |
Volume (l) |
82.69 |
PSU form factor |
ATX PS/2 |
Net weight (kg) |
18.0 |
Expansion slots |
8 |
PRE-INSTALLED FANS |
|
Fan at front |
2x Silent Wings 4 140mm PWM White |
Fan at rear |
1x Silent Wings 4 140mm PWM White |
Dimensions (L x W x H), (mm) |
Front: 140 x 140 x 25 / Rear: 140 x 140 x 25 |
Fan speed at 100% PWM / 12V (rpm) |
1900 |
Airflow at 100% PWM / 12V (CFM / m3/h) |
78.4 / 133.2 |
Air Pressure at 100% PWM / 12V (mm H2O) |
2.36 |
Noise level at 100% PWM / 12V (dB(A)) |
29.3 |
Voltage range (V DC) |
12 |
Input power (W) |
4.8 |
Input current (A) |
0.4 |
Connector |
4-pin PWM |
Lifespan (h / 25°C) |
300,000 |
Fan controller |
5-step fan controller with 2x PWM Hubs |
MAXIMUM FAN INSTALLATION |
|
Maximum fans |
11 |
Top (mm) |
3x 140 / 3x 120 |
Front (mm) |
3x 140 / 3x 120 |
Side (mm) |
3x 120 |
Rear (mm) |
1x 140 / 1x 120 |
Bottom (mm) |
1x 140 / 1x 120 |
PSU COMPATIBILITY |
|
Maximum dimensions excl. bottom fan (mm) |
325 |
Maximum dimensions incl. bottom fan (mm) |
325 |
GRAPHICS CARD |
|
HDD cage (in height of graphics card) installed (mm) |
350 / 370 |
HDD cage (in height of graphics card) removed (mm) |
495 |
Maximum PCIe slots with vertical graphics card (pcs.) |
8 |
DRIVE BAY CAPACITY |
|
5.25 bays (pcs.) |
1 |
3.5 slots (scope of delivery) |
2 |
3.5 slots (max.) |
7 |
2.5 slots (scope of delivery) |
6 |
2.5 slots (max.) |
16 |
COOLING |
|
Max.construction height of CPU cooler unit (mm) |
190 |
LIGHTING |
|
LED illumination |
Yes |
LEDs (pcs.) |
8 + 16 |
LED type |
ARGB - 5V |
LEDs synchronizable with controller/motherboard |
Yes |
I/O PANEL |
|
USB 3.2 Gen. 2 Type C |
1 |
USB 3.2 Type A |
4 |
HD Audio I/O |
Mic + Audio |
Qi charger / Quick Charging Option (W) |
15 |
INSULATION AND DAMPING |
|
Top panel insulation mats |
? |
Front panel insulation mats |
? |
Side panel insulation mats |
? |
Anti-vibration decoupled HDD |
? |
Anti-vibration decoupled fan |
? |
Anti-vibration decoupled PSU |
? |
Anti-vibration decoupled motherboard-tray |
? |
SCOPE OF DELIVERY |
|
Screw set (Drives/Motherboard) |
? |
SSD bracket for PSU shroud |
3 (for E-ATX) |
Cable ties (pcs.) |
12 |
Screw box |
? |
VGA holder |
? |
VGA holder for inverted layout |
? |
Mesh Front Panel |
? |
ODD Bracket |
? |
Fan / Radiator bracket for multi mounting panel |
? |
REMOVEABLE DUST FILTERS |
|
Front |
1 |
Bottom |
1 |
MATERIAL |
|
Top cover |
Aluminum |
Front panel |
Aluminum |
Side panel |
Glass |
Side panel window |
Steel |
Stands |
Steel |
