Description

SPECIFICATIONS:
GENERAL |
|
TDP (W) |
280 |
Color option |
Black |
Overall dimensions |
145 x 136 x 168 |
Total weight (kg) |
1.34 |
Socket compatibility Intel |
1700 / 1200 / 1150 / 1151 / 1155 |
Socket compatibility AMD |
AM5 / AM4 |
Overall noise level (dB(A)) @ 50/75/100% (rpm) |
11 / 19.5 / 25.8 |
Number of fans |
2 |
Lighting connector |
✓ |
HEATSINK |
|
Dimensions (L x W x H), (mm) |
120 x 136 x 168 |
Fin material |
Aluminum |
Surface treatment |
Ceramic coating |
Base material |
Copper |
CPU contact surface |
CNC machined |
Heatpipe number / Diameter (mm) |
7 / 6 |
FAN |
|
Fan model |
Silent Wings |
Fan dimensions (mm) |
135 x 135 x 25 |
Speed @ 100% PWM /12V (rpm) |
1500 / 2000 |
Bearing technology |
Fluid Dynamic Bearing |
Motor technology |
6-pole fan motor |
Rated Voltage (V) |
12 |
Input current (A) |
0.40 |
Input power (W) |
4.8 |
Connector |
4-pin PWM |
Cable length (mm) |
120 / 80 |
Lifespan (h / 25°C) |
300,000 |
Y-Cable |
✓ |
ACCESSORIES |
|
Thermal grease (Type) |
Included |
Mounting set |
Intel & AMD |
Y-Cable |
✓ |
User manual languages |
CN, DE, EN, ES, FR, JP, PL, RU, TW |
SAFETY CERTIFICATION |
|
Approvals |
CE, UKCA, UL, TÜV |
ENVIRONMENTAL DIRECTIVES |
|
RoHS |
✓ |
WEEE |
✓ |
Triman |
✓ |
