Description
SPECIFICATIONS:
GENERAL |
|
TDP (W) |
270 |
Color option |
Black |
Overall dimensions without mounting material |
145 x 136 x 168 |
Total weight (kg) |
1.29 |
Socket compatibility Intel |
1700 / 1200 / 1150 / 1151 / 1155 |
Socket compatibility AMD |
AM5 / AM4 |
Overall noise level (dB(A)) @ 50/75/100% (rpm) |
8.9 / 16.3 / 23.3 |
Number of fans |
2 |
HEATSINK |
|
Dimensions (L x W x H), (mm) |
119.5 x 136 x 168 |
Fin material |
Aluminum |
Surface treatment |
Ceramic coating |
Base material |
Copper |
CPU contact surface |
CNC machined |
Heatpipe number / Diameter (mm) |
7 / 6 |
FAN |
|
Fan model |
Silent Wings / Silent Wings 4 |
Fan dimensions (mm) |
135 x 135 x 25 / 120 x 120 x 25 |
Speed @ 100% PWM /12V (rpm) |
1300; 1500 / 1700; 2000 |
Bearing technology |
Fluid Dynamic Bearing |
Motor technology |
6-pole fan motor |
Rated Voltage (V) |
12 |
Input current (A) |
0.28 / 0.20 |
Input power (W) |
3.36 / 2.4 |
Connector |
4-pin PWM |
Cable length (mm) |
120 / 80 |
Lifespan (h / 25°C) |
300,000 |
Y-Cable |
✓ |
