Description
SPECIFICATIONS:
GENERAL |
|
Color option |
Black |
Motherboard compatibility |
E-ATX / XL-ATX / ATX / M-ATX / Mini-ATX |
Case size excl. stands (L x W x H), (mm) |
532 x 327 x 465 |
Case size incl. stands (L x W x H), (mm) |
532 x 327 x 484 |
Volume (l) |
68 |
PSU form factor |
ATX PS/2 |
Net weight (kg) |
15.3 |
Expansion slots |
8 |
MAXIMUM FAN INSTALLATION |
|
Maximum fans |
10 |
Top (mm) |
3x 140 / 3x 120 |
Side (mm) |
3x 140 / 3x 120 |
Rear (mm) |
1x 140 / 1x 120 |
Bottom (mm) |
3x 140 / 3x 120 |
OPTIONAL RADIATOR INSTALLATION |
|
Top (mm) |
120 / 140 / 240 / 280 / 360 / 420 |
Side (mm) |
120 / 140 / 240 / 280 / 360 |
Rear (mm) |
120 / 140 |
Bottom (mm) |
120 / 140 / 240 / 280 / 360 / 420 |
PSU COMPATIBILITY |
|
Maximum dimensions excl. bottom fan (mm) |
225 |
Maximum dimensions incl. bottom fan (mm) |
225 |
GRAPHICS CARD |
|
HDD cage (in height of graphics card) installed (mm) |
495 |
HDD cage (in height of graphics card) removed (mm) |
495 |
Maximum PCIe slots with vertical graphics card (pcs.) |
4 |
DRIVE BAY CAPACITY |
|
3.5 slots (scope of delivery) |
1 |
3.5 slots (max.) |
2 |
2.5 slots (scope of delivery) |
4 |
2.5 slots (max.) |
6 |
COOLING |
|
Max.construction height of CPU cooler unit (mm) |
190 |
LIGHTING |
|
LED illumination |
? |
LEDs (pcs.) |
172 |
LED type |
ARGB - 5V |
LEDs synchronizable with controller/motherboard |
? |
I/O PANEL |
|
USB 3.2 Gen. 2 Type C |
1 |
USB 3.2 Type A |
2 |
HD Audio I/O |
Mic + Audio |
INSULATION AND DAMPING |
|
Anti-vibration decoupled HDD |
? |
Anti-vibration decoupled fan |
? |
Anti-vibration decoupled PSU |
? |
SCOPE OF DELIVERY |
|
Screw set (Drives/Motherboard) |
? |
Additional standoffs (pcs.) |
1 |
Cable ties (pcs.) |
12 |
