Description
SPECIFICATIONS:
HEADPHONE |
|
Transducer type |
Dynamic |
Operating principle |
Open |
Wearing type |
Over-ear |
Frequency response |
5 - 40,000 Hz |
Nominal impedance |
48Ωper system |
Sound pressure level 96 dB |
@ 1 mW/500 Hz |
T.H.D. |
@ 500 Hz < 0.05 % |
Power handling capacity |
30 mW |
Ambient noise attenuation |
18 dBA |
Headband pressure |
5.5 N |
Weight |
318 g |
MICROPHONE |
|
Transducer type |
Condenser (back electret) |
Operating principal |
Pressure gradient |
Polar pattern |
Cardioid |
Power supply |
AB powering |
Supply voltage |
2 - 9 V |
Current consumption |
0.6 mA |
Sensitivity at f = 1 kHz |
21.6 mV/Pa |
Frequency response |
20 - 20,000 Hz |
Max. sound pressure level |
121 dB |
Microphone output |
Unbalanced |
Length mic boom |
Approx. 190 mm |
Capsule diameter |
13 mm |
