Description
SPECIFICATIONS:
BASIC SPECS |
|
Scanning Speed |
30ppm/300dpi, 7ppm/600dpi |
Document Size - Multiple Sheets - Width |
50.8 mm to 215.9 mm |
Document Size - Multiple Sheets - Length |
70 mm to 355.6 mm |
Colour / Monochrome |
Yes / Yes |
2-Sided (Duplex) Scan |
Yes |
Colour Depth - Input |
48 bit colour processing |
Colour Depth - Output |
24 bit colour processing |
Resolution - Optical |
Up to 600 x 600 dpi |
Resolution - Interpolated |
Up to 1200 x 1200 dpi |
Document Scanning Width / Length |
Up to 215.9 mm |
Product Dimensions (Width X Depth X Height) |
288 mm × 101 mm × 85 mm |
Weight |
1.42 kg |
ADF (Automatic Document Feeder) |
Up to 20 sheets |
Memory Capacity |
SDRAM: 512MB |
CONNECTIVITY |
|
Connectivity |
Wireless LAN IEEE 802.11 b/g/n (Infrastructure Mode), IEEE 802.11 g/n (Wi-Fi Direct) |
NETWORK |
|
Wireless Network Security |
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES) |
Setup Support Utility |
WPS |
DISPLAY TYPE |
|
Touchscreen LCD |
2.8"(71.1mm) Colour Touchscreen LCD |
OPERATION |
|
Power Source |
AC Adapter (optional): 100 - 240 V AC 50/60 Hz DC: 5V, 3A |
Power Consumption - Scanning |
AC: Approximately 12 W DC: Approximately 10 W |
Power Consumption - Ready |
AC: Approximately 6.4 W DC: Approximately 5.2 W |
Power Consumption - Power Saving / Deep Sleep |
AC: Approximately 1.5 W DC: Approximately 1.1 W |
Power Consumption - Power OFF |
AC: Approximately 0.1 W DC: Approximately 0.1 W |
Temperature Operating |
5 ℃ to 35 ℃ |
Humidity - Operating |
20% to 80% |
Humidity - Storage |
10% to 90% |
COMPLIANCE |
|
TWAIN Compliant - Windows® |
Windows 10 / 11 |
WIA Compliant - Windows® |
Windows 10 / 11 |
