Description
SPECIFICATIONS:
Speaker Configuration |
Soundbar |
Connector Type |
HDMI ARC, USB-in, Optical-in (TOSLINK), Aux-in, Headset-out, SXFI-out, DC-in |
Operating Temperature |
0—40°C |
Dimensions |
650 x 109 x 78 mm / 25.6 x 4.3 x 3.1 inches |
Weight |
Soundbar: 2.67 kg / 5.90 lbs |
Cable Length (End-to-end) |
Optical Cable: 1.5m / 4.92 ft, USB-C to USB-A Cable: 1.2m (3.94 ft), Power Cord: 1.5 m / 4.92 ft |
Frequency Response |
55–20,000 Hz |
Power Output |
Total System Power: Up to 90W RMS, Peak Power: 180W |
Bluetooth® Version |
5.0 |
Profiles |
(AVRCP) Audio / Video Remote Control Profile, (A2DP) Advanced Audio Distribution Profile |
Operating Frequency |
2402–2480 MHz |
Operating Range |
Up to 10m / 33 ft*, *Measured in open space. Walls and structures may affect range of device. |
Wireless Codecs |
SBC |
Package Contents |
Optical Cable (Toslink), USB-C to USB-A Cable (1.2m / 3.94 ft) |
System Requirements |
For Analogue Audio (Stereo): Devices that support 3.5mm stereo to stereo connection
For Wireless Audio Streaming (Stereo): Compatible Bluetooth devices that support the Stereo Bluetooth Profile (A2DP)
For Wireless Audio Control: Compatible Bluetooth devices that support the Bluetooth Remote Control (AVRCP)
For 5.1 Surround Audio Playback over USB: Windows® PC, Mac OS, PS4, PS5
For Dolby Audio 5.1 Audio Playback: Dolby® Audio (Dolby Digital) source connected to Optical-in and HDMI-ARC
For USB Audio and High-resolution 24-bit 96kHz USB Audio Playback: Windows® PC, Mac OS via USB Connection For Headset Out: Supports 3.5mm headset 4 pole output with mic
For SXFI Out: SXFI Theatre Headphone
For Creative application: Microsoft® Windows® 10 32-bit or 64-bit, USB 2.0/3.0 port iOS 11.0 or later Android 7.0 and above |
Package Contents |
1 x Sound Blaster Katana SE 1 x Remote Control* 1 x Power Adapter 1 x Mains Cables 1 x TOSLINK Optical Cable 1 x USB-C to USB-A Cable 1 x Quick Start Guide 2 x Wall Mount Brackets * Batteries not included |
