Description
SPECIFICATIONS:
Colour |
Blue |
Cable Length |
1m |
Compliant Standard |
TIA-568-C.2-2009, ISO/IEC 11801(Ed. 2.2) |
Suitable for |
10BASE-T, 100BASE-TX, 1000BASE-T/1000BASE-TX, 10GBaseT, PoE, PoE+ |
Conductor Type |
BC 4*2*28AWG (7*0.12mm) OFC(Oxygen Free Copper) |
Shielding Types |
SF/FTP Triple Shielding (individual foil shielding twisted pair, overall Aluminium Magnesium braid shielding and Aluminium foil shielding) |
Connector |
Gold-plated RJ45, nickel-plated copper shell |
Wiring Scheme |
T568B |
Transfer Rate |
Up to 10Gbps |
Bandwidth |
Up to 600MHz |
Sheath |
PVC |
Insulation |
HDPE |
Outside Diameter |
6.2±0.3mm |
Minimum Bend Radius |
45.5mm |
