Typical Applications |
|
Features |
-
GreenPower UPS Technology
-
Automatic Voltage Regulation (AVR)
-
EMI, RFI, Surge and Lightning Spike Protection
-
Phone / Fax / Modem / DSL / Network Protection
-
Auto-Restart / Auto-Charge
-
LCD Status Monitor
-
USB Connectivity Port
-
User-Replaceable Batteries
-
Horizontal / Wall-Mounted Use
-
Cable Collector Included
-
External Battery Charger
-
USB Charging Port
-
PowerPanel® Personal Edition Software
|
General |
UPS Topology Line-interactive Energy Saving Yes |
Input |
Voltage 220/230/240 Vac Input Voltage Range 170Vac - 290Vac Input Frequency Range 45-65Hz Rated Input current 5.45A Plug Type AU Plug Style Straight Angle Cord Length (ft.) 5 Cord Length (m) 1.5 |
Output |
VA 1200 Watts 720 On Battery Waveform Simulated Sine Wave On Battery Voltage 220-240Vac Automatic Voltage Regulation (AVR) Single Boost / Single Buck Automatic Voltage Regulation (Line Mode) Boost Mode Voltage: Vinx1.18Buck Mode Voltage: Vinx0.85 On Battery Frequency 50/60Hz ± 1% Overload Protection On Utility: Circuit Breaker & Inter'N/Al circuitry limiting / On Battery: Inter'N/Al Current Limiting Outlets - Total 8 Outlet Type AU Outlets - Battery & Surge Protected 4 Outlets - Surge-Only Protected 4 USB Charging Ports Yes Rated Power Factor 0.6 Transfer Time 4ms |
Battery |
Runtime at Half Load (min) 6 Runtime at Full Load (min) 1 Battery Type Sealed Lead Acid Battery Number MH/MS5-12HR Battery Size 12V/5.8AH Battery Quantity 1 User Replaceable Yes Hot-Swappable Yes Typical Recharge Time 8 Hours Replacement Battery Pack RBP0063 Replacement Battery Pack Quantity 2 |
Surge Protection & Filtering |
Surge Suppression 125 Joules (L-N) Phone / Network Protection RJ11/RJ45 1-In, 1-Out (Combo) |
Management & Communications |
LCD Control Panel Yes Multifunction LCD Diagnostic Display Battery Capacity, Load Capacity, Estimated run time, Input voltage, Output voltage, Line mode Icon, Battery mode Icon, Overloaded Icon, Silent mode Icon, Fault Icon HID Compliant USB Port Yes Management Cable USB&Phone Cable LED Indicators YES Audible Alarms On Battery, Low Battery, Overload, Fault Software PowerPanel® Personal Edition |
Physical |
Form Factor Brick Enclosure Construction Plastic Mounting Hardware Yes |
Physical - UPS Module |
Dimensions (WxHxD) (mm.) 166x118x288 Weight (kg.) 8.2 |
Environmental |
Operating Temperature + 32°F to 104° F / 0° C to 40° C Operating Humidity 0% - 90% non-condensing Operating Elevation 0-10000 feet (0-3000meters) Storage Temperature - 4°F to 122° F / -20° C to 50° C Storage Relative Humidity 0% - 90% Storage Elevation 0-3000 meters Online Thermal Dissipation 137 BTU/hr Audible noise at 1.5M from surface of unit <40db< td=""> |
Certifications |
Certifications CE/RCM RoHS RoHS Compliant |
Warranty
|
roduct Warranty 2 Years Limited Connected Equipment Guarantee Lifetime CEG Amount 75000 AUD |
