GENERAL
|
|
Phase
|
Single Phase
|
Form Factor
|
Rackmount, Tower
|
UPS Topology
|
Online Double Conversion
|
Energy Saving Technology
|
Online ECO Mode Efficiency > 95%
|
Active PFC Compatibility
|
Yes
|
INPUT
|
|
Generator Compatibility
|
Yes
|
Nominal Input Voltage ( Vac )
|
230 ± 10%
|
Input Voltage Range ( Vac )
|
190 ~ 300
|
Adjustable Voltage Range ( Vac )
|
0~30% Load for 80 ~ 300 Vac
0~60% Load for 140 ~ 300 Vac
0~80% Load for 160 ~ 300 Vac
0~100% Load for 190 ~ 300 Vac
|
Input Frequency ( Hz )
|
50 ± 10
60 ± 10
|
Input Frequency Detection
|
Auto-sensing
|
Rated Input Current ( A )
|
13
|
Input Power Factor
|
0.99
|
Input Connector Type
|
IEC C20
|
Detachable Power Cord Plug Type
|
Schuko x 1
|
Power Cord Length (ft.)
|
5
|
Power Cord Length (m.)
|
1.5
|
OUTPUT
|
|
Capacity (VA)
|
3000
|
Capacity (Watts)
|
2700
|
On Battery Waveform
|
Pure Sine Wave
|
On Battery Voltage(s) ( Vac )
|
208 ± 1%
220 ± 1%
230 ± 1%
240 ± 1%
|
Output Voltage Setting
|
Configurable
|
On Battery Frequency ( Hz )
|
50 ± 0.5%
60 ± 0.5%
|
Output Frequency Setting
|
Configurable
|
Power Factor
|
0.9
|
ECO Mode Voltage Tolerance
|
± 15 %
|
Overload Protection
|
Internal Current Limiting, Circuit Breaker, Fuse
|
Overload Protection (Line Mode)
|
110~120% Load for 1 min, >120% Load Immediately
|
Overload Protection (Battery Mode)
|
110~120% Load for 10 sec, >120% Load Immediately
|
Overload Protection (Bypass Mode)
|
>130% Load Immediately
|
Crest Factor
|
3 : 1
|
Harmonic Distortion (Linear Load)
|
THD<3%
|
Harmonic Distortion (Non-linear Load)
|
THD<5%
|
Internal Bypass
|
Automatic Bypass, Manual Bypass
|
Outlet(s) - Total
|
9
|
Outlet Type
|
IEC C19 x 1
IEC C13 x 8
|
Outlet(s) - Battery & Surge Protected
|
9
|
Outlet(s) - Critical Load (CL)
|
5
|
Outlet(s) - Non-Critical Load (NCL)
|
4
|
Typical Transfer Time ( ms )
|
0
|
BATTERY
|
|
Runtime at Half Load ( min )
|
13.8
|
Runtime at Full Load ( min )
|
4.3
|
Typical Recharge Time ( Hours )
|
4
|
Maximum Charging Current ( A )
|
1.5
|
Start On Battery
|
Yes
|
Smart Battery Management (SBM)
|
Yes
|
User-replaceable
|
Yes - Qualified Personnel Only
|
Battery Type
|
Sealed Lead-acid
|
Replacement Battery Pack
|
RBP0158
|
RBP Quantity ( pcs )
|
1
|
Battery Quantity (Each RBP) ( pcs )
|
6
|
Battery Voltage (Each RBP) ( V )
|
72
|
Compatible Extended Battery Module (EBM)
|
BPSE72V40ART2U
|
Extended Battery Module Auto-detection
|
Yes
|
Max. EBM Quantity ( pcs )
|
3
|
SURGE PROTECTION & FILTERING
|
|
Surge Suppression ( Joules )
|
388
|
EMI/RFI Filtration
|
Yes
|
Phone/Network Protection RJ11/RJ45 (Combo)
|
1-in, 1-out
|
MANAGEMENT & COMMUNICATIONS
|
|
LCD Panel
|
Yes
|
LCD Types
|
Colour LCD
|
LCD Information Display
|
Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
|
LCD Setting & Control
|
Mode Setting, Alarm Setting, Input & Output, Battery Setting
|
HID Compliant USB Port(s)
|
1
|
Dry Contact (with Relay)
|
Yes
|
Emergency Power Off (EPO) Port
|
Yes
|
Audible Alarms
|
Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery
|
Management Cable ( pcs )
|
Power Cord x2, USB Cable x1
|
Power Management Software
|
PowerPanel® Business (Recommended)
|
SNMP/HTTP Remote Monitoring
|
Yes - with optional RMCARD205
|
PHYSICAL
|
|
Enclosure Construction
|
Metal
|
Colour
|
Black
|
Rackmount Rail
|
Yes
|
Rackmount Ears
|
Yes
|
PHYSICAL SIZE - UPS MODULE
|
|
Dimensions (WxHxD) (in.)
|
17.24 x 3.46 x 24.2
|
Dimensions (WxHxD) (mm.)
|
438 x 88 x 610
|
Weight (lbs.)
|
58.8
|
Weight (kg.)
|
26.7
|
Installed Rack Height ( U )
|
2
|
SHIPPING DIMENSIONS
|
|
Dimensions (WxHxD) (in.)
|
21.3 x 9 x 28.7
|
Dimensions (WxHxD) (mm.)
|
540 x 230 x 730
|
Weight (lbs.)
|
69.1
|
Weight (kg.)
|
31.3
|
ENVIRONMENTAL
|
|
Operating Temperature (°F)
|
32 ~ 104
|
Operating Temperature (°C)
|
0 ~ 40
|
Operating Relative Humidity (Non-condensing) ( % )
|
20 ~ 90
|
Operating Elevation ( feet/meters )
|
0-4,921 feet (0-1,500 meters)
|
Storage Temperature (°F)
|
-4 ~ 122
|
Storage Temperature (°C)
|
-20 ~ 50
|
Storage Relative Humidity (Non-condensing) ( % )
|
10 ~ 90
|
Storage Elevation ( feet/meters )
|
0-4,921 feet (0-1,500 meters)
|
Online Thermal Dissipation ( BTU/hr )
|
911
|
Variable Speed Fans
|
20 steps automatically
|
CERTIFICATIONS
|
|
Certifications
|
CE, EAC
|
RoHS
|
Yes
|
