Description
CyberPower PFC Sinewave Series 900VA/540W (10A) Tower UPS with LCD and 6 AU Outlets
CyberPower CP900EPFCLCDa with Pure Sine Wave output safeguards mid- to high-end computer systems, servers and networking hardware that use conventional and Active Power Factor Correction (PFC) power supplies. Designed with GreenPower UPS™ Technology to improve UPS operating efficiency and to minimize its energy consumption, users can enjoy significant energy cost savings over conventional UPS systems.
The UPS provides Automatic Voltage Regulation (AVR) to maintain safe voltage levels for connected equipment. Featured data line protection guards phones, networks, and communication equipment against surges/spikes and other power irregularities. With multifunction LCD display, users can access information of power/battery conditions and configure advanced settings, including alert of potential power problems and self-test with a single push of a button.
Line-interactive UPS Topology
Active PFC Compatible
Automatic Voltage Regulation (AVR)
LED Status Indicator
Surge and Spike Protection
Tower Form Factor
Energy Saving Technology
Pure Sine Wave Output
LCD Status Display
PowerPanel Management Software
Phone/Fax/Modem/DSL/Network Protection
SPECIFICATIONS:
GENERAL |
|
Phase |
Single Phase |
Form Factor |
Tower |
UPS Topology |
Line-interactive |
Energy Saving Technology |
GreenPower UPS™ Bypass Technology |
Active PFC Compatibility |
Yes |
INPUT |
|
Nominal Input Voltage ( Vac ) |
230 |
Input Voltage Range ( Vac ) |
170 ~ 270 |
Input Frequency ( Hz ) |
50 ± 3 60 ± 3 |
Input Frequency Detection |
Auto-sensing |
Rated Input Current ( A ) |
10 |
Input Connector Type |
IEC C14 |
Detachable Power Cord Plug Type |
AU x 1 |
Power Cord Length (ft.) |
6 |
Power Cord Length (m.) |
1.83 |
OUTPUT |
|
Capacity (VA) |
900 |
Capacity (Watts) |
540 |
On Battery Waveform |
Pure Sine Wave |
On Battery Voltage(s) ( Vac ) |
230 ± 10 % |
On Battery Frequency ( Hz ) |
50 ± 1% 60 ± 1% |
Automatic Voltage Regulation (AVR) |
Single Boost |
Overload Protection |
Internal Current Limiting, Circuit Breaker |
Outlet(s) - Total |
6 |
Outlet Type |
AU x 6 |
Outlet(s) - Battery & Surge Protected |
3 |
Outlet(s) - Surge-Only Protected |
3 |
Typical Transfer Time ( ms ) |
4 |
BATTERY |
|
Runtime at Half Load ( min ) |
7 |
Runtime at Full Load ( min ) |
1 |
Typical Recharge Time ( Hours ) |
8 |
Start On Battery |
Yes |
User-replaceable |
Yes |
Battery Type |
Sealed Lead-acid |
Battery Cartridge (RBP) |
RBP0007 |
Battery Cartridge (RBP) Quantity ( pcs ) |
1 |
SURGE PROTECTION & FILTERING |
|
Surge Suppression ( Joules ) |
405 |
EMI/RFI Filtration |
Yes |
Phone/Network Protection RJ11/RJ45 (Combo) |
1-in, 1-out |
MANAGEMENT & COMMUNICATIONS |
|
LCD Panel |
Yes |
LCD Information Display |
Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log |
LCD Setting & Control |
Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Event & Log |
LED Indicators |
Power On |
HID Compliant USB Port(s) |
1 |
Audible Alarms |
Battery Mode, Low Battery, Overload, UPS Fault |
Management Cable ( pcs ) |
Power Cord x2, USB Cable x1 |
Ethernet Data Transmission Speed |
Up to 1Gbps |
Power Management Software |
PowerPanel Personal (Recommended) |
PHYSICAL |
|
Enclosure Construction |
Plastic |
Color |
Black |
PHYSICAL SIZE - UPS MODULE |
|
Dimensions (WxHxD) (in.) |
3.9 x 9.1 x 10.8 |
Dimensions (WxHxD) (mm.) |
100 x 230 x 275 |
Weight (lbs.) |
15.7 |
Weight (kg.) |
7.1 |
ENVIRONMENTAL |
|
Operating Temperature (°F) |
32 ~ 104 |
Operating Temperature (°C) |
0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % ) |
0 ~ 95 |
Operating Elevation ( feet/meters ) |
0-9,843 feet (0-3,000 meters) |
Storage Temperature (°F) |
5 ~ 113 |
Storage Temperature (°C) |
-15 ~ 45 |
Storage Relative Humidity (Non-condensing) ( % ) |
0 ~ 95 |
Storage Elevation ( feet/meters ) |
0-4,921 feet (0-1,500 meters) |
Online Thermal Dissipation ( BTU/hr ) |
31 |
Audible Noise at 1.0M from Surface of Unit ( dBA ) |
34.2 |
CERTIFICATIONS |
|
Certifications |
CE, EAC, RCM |
RoHS |
Yes |
OTHERS |
|
What’s in the Box |
CP900EPFCLCDA UPS Power Cord USB Cable User's Manual * Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide. |
