Description
SPECIFICATIONS:
Net Weight |
1632 g |
Radiator Dimensions |
402×120×27 mm(L×W×H) |
Radiator Material |
Aluminum |
Tube length |
410 mm(L×W×H) |
Pump Dimensions |
91×78×65 mm(L×W×H) |
Pump Speed |
2500~3400 RPM±10% |
Pump Connector |
4-pin PWM |
Pump Rated Voltage |
12 VDC |
Pump Rated Current |
0.29 A |
Pump Power Consumption |
3.48 W |
Fan Dimensions |
120×120×25 mm(L×W×H) |
Fan Speed |
500~2100 RPM±10% |
Fan Airflow |
75.89 CFM |
Fan Air Pressure |
2.53 mmAq |
Fan Noise |
≤31.6 dB(A) |
Fan Connector |
4-pin PWM |
Bearing Type |
Hydro Bearing |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.17 A |
Fan Power Consumption |
2.04 W |
LED Type |
Addressable RGB LED |
LED Connector |
3-pin(+5V-D-G) |
LED Rated Voltage |
5 VDC |
LED Power Consumption |
2.8 W（PUMP）/ 3.15 W（FAN×3） |
Application For |
Intel LGA1851/1700/1200/1151/1150/1155 AMD AM5/AM4 |
