Description
SPECIFICATIONS:
TECHNICAL INFORMATION |
|
Diagonal Viewing Size |
23.8" |
Preset Display Area (H x V) |
527.04 mm x 296.46 mm (20.75" x 11.67") |
Panel Type |
In-Plane Switching (IPS) technology |
Display Screen Coating |
Anti-glare with 3H hardness |
Maximum Preset Resolution |
1920 x 1080 |
Refresh rate |
100 Hz |
Viewing Angle |
178° vertical / 178° horizontal |
Pixel Pitch |
0.2745 mm x 0.2745 mm |
Pixel Per Inch (PPI) |
92.53 |
Contrast Ratio |
1,500: 1 (typical) |
Aspect Ratio |
16:9 |
Backlight Technology |
LED edgelight system |
Brightness |
250 cd/m2 (typical) |
Response Time |
5ms gray-to-gray (Fast mode) 8ms gray-to-gray (Normal mode) |
Colour Support |
Up to 16.7 million colours |
Colour Gamut |
99% sRGB |
TÜV Eye Comfort |
Yes, 4-Star |
Ficker Free |
Yes |
Connectivity |
1x HDMI 1.4 (HDCP 1.4) (Supports up to FHD 1920 x 1080 100Hz TMDS as per specified in HDMI 1.4) 1x DP 1.2 (HDCP 1.4) 1x VGA 1x USB 3.2 Gen1 Type-B upstream 3x USB 3.2 Gen1 Type-A downstream 1x USB 3.2 Gen1 Type-C downstream with up to 15W PD (data only) |
Built-in Speaker |
No |
USB Power Delivery |
Yes, up to 15W via USB-C downstream port |
Adjustability |
Height, Tilt, Swivel, Pivot |
Height |
Up to 150 mm (5.9") |
Tilt |
-5°/+21° |
Swivel |
-45°/+45° |
Pivot |
-90°/+90° |
Dell Display Manager Compatibility |
Yes with Easy Arrange |
Remote Asset Management |
Yes |
Voltage Required |
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A (typ) |
Power Consumption (Operational) (typical) |
0.3 W (Off mode) 0.3 W (Standby mode) 11.7 W (On mode) 65 W (Max) 12.0 W (Pon) 38.4 kWh (TEC) |
Audio Output |
Optional soundbar (sold separately) |
Security |
Security-lock slot (based on Kensington Security Slot™) |
Compliant Standards |
ENERGY STAR certified monitor EPEAT GOLD EPEAT Climate+ TCO Certified Displays TCO Certified Edge RoHS-compliant BFR / PVC free monitor (excluding external cables) Arsenic-free glass and mercury-free (panel only) |
Flat Panel Mount Interface |
VESA (100 mm x 100mm) |
Temperature Range |
Operating: 0°C ~ 40°C (32°F ~ 104°F) Non-operating: -20° ~ 60°C (-4° ~ 140°F) |
Humidity Range |
Operating: 10% ~ 80% (non-condensing) Non-operating: 5% ~ 90% (non-condensing) |
Altitude |
Operating: 5,000 m (16,404 ft) max Non-operating: 12,192 m (40,000 ft) max |
What's Included |
1x Monitor panel 1x Stand riser and base 1x Quick setup guide 1x Safety, Environmental, and Regulatory Information |
Cables Included |
1x Power cord 1x DP-to-DP cable, 1.8m 1x USB 3.2 Gen1 Type A-to-B (upstream) cable, 1.8m |
PHYSICAL CHARACTERISTICS |
|
Height with stand (Compressed ~ Extended) |
364.00 mm ~ 496.53 mm |
Width with stand |
538.64 mm |
Depth with stand |
181.75 mm |
Height without stand |
314.23 mm |
Width without stand |
538.64 mm |
Depth without stand |
50.03 mm |
Weight (panel only - for VESA mount) |
3.12 kg |
Weight (with packaging) |
6.78 kg |
