Description
SPECIFICATIONS:
TECHNICAL INFORMATION |
|
Number of Screens |
1 |
Screen Size Class |
32" |
Viewable Screen Size |
31.5" |
Screen Mode |
3840 x 2160 UHD |
Panel Technology |
In-plane Switching (IPS) Black Technology |
Response Time Details |
5ms GTG (Fast) 8ms GTG |
Aspect Ratio |
16:9 |
Pixel Pitch |
0.18159 mm x 0.18159 mm |
Horizontal Viewing Angle |
178° |
Vertical Viewing Angle |
178° |
Mount Type |
Panel Mount |
Backlight Technology |
LED Edgelight System |
HDCP Supported |
Yes |
Maximum Adjustable Height |
150 mm |
Tilt Angle |
-5° to 21° |
Swivel Angle |
-30° to 30° |
Pivot Angle |
-90° to 90° |
Features |
VESA DisplayHDR 600 Eye Comfort Technology Narrow Bezel Mercury-free Arsenic-free Glass Low reflectance with anti-glare and hard-coating 3H PVC Free BFR Free Picture by Picture Picture in Picture Cable Lock Slot Security Lock Ambient Light Sensor Color Calibration |
Horizontal Frequency |
30 kHz to 275 kHz |
Vertical Frequency |
48 Hz to 120 Hz |
Adjustable Stand |
Yes |
Stand Adjustments |
Swivel, Height, Pivot, Tilt |
Stand Included |
Yes |
Glass Hardness |
3H |
Soundbar Compatibility |
Optional soundbar (sold separately) |
VIDEO |
|
Maximum Resolution |
3840 x 2160 |
Standard Refresh Rate |
3840 x 2160 up to 120 Hz |
Colour Supported |
1.07 Billion Colours |
Native Contrast Ratio |
3,000:1 |
Brightness |
450 cd/m2 600 cd/m2 |
Colour Gamut |
DCI-P3 99% (CIE1976) (typical), Display P3 99%, sRGB 100% (CIE1931) (typical), BT.709 100%, Delta E <1.5 (Average) |
Pixel Per Inch (PPI) |
140 |
INTERFACES/PORTS |
|
Connectivity |
1 DisplayPort 1.4 port with DSC support (DRR for Microsoft Windows) 1 DisplayPort 1.4 port out 1 HDMI port (Supports up to UHD 3840 x 2160 120Hz FRL, VRR as per specified in HDMI2.1) 1 Thunderbolt 4 upstream port (DP1.4 (HDCP 2.2) with DSC support, PD: Up to 140W EPR, 2/4 Lanes switching) 1 Thunderbolt 4 downstream port (Downstream, Daisy Chain, 15 W) 1 USB-C (USB 10Gbps KVM) upstream port 1 Analog 2.0 audio line out port (3.5 mm jack) 4 USB Type-A ports 10Gbps 1 RJ45 Ethernet port, 2.5GbE
Quick Access port: 1 USB Type-A 10Gbps port with BC 1.2 2 USB-C 10Gbps downstream ports |
USB Type-C (Power Delivery) |
Up to 140W EPR |
Audio Line Out |
Yes |
BUILT-IN DEVICES |
|
Built-in Devices |
Ambient Light Sensor |
ENVIRONMENTAL CONDITIONS |
|
Operating Temperature Range |
0°C) to 40°C) |
Non-operating Temperature Range |
-20°C to 60°C |
Operating Humidity Range |
10% to 80% (Non-condensing) |
Non-operating Humidity Range |
5% to 90% (Non-condensing) |
Maximum Operating Altitude |
4998.72 m |
Maximum Non-operating Altitude |
12192 m |
POWER DESCRIPTION |
|
Input Voltage Range |
100V AC to 240V AC |
Operating Power Consumption |
30.50 W |
Standby Power Consumption |
0.5 W |
Off-Mode Power Consumption |
0.3 W |
Frequency |
60 Hz 50 Hz |
Maximum Power Consumption |
335 W |
Voltage Current |
4.20 Ah |
PHYSICAL CHARACTERISTICS |
|
VESA Mount Compatible |
Yes |
VESA Mount Standard |
100 x 100 |
Height |
410.34 mm |
Width |
713.20 mm |
Depth |
57.50 mm |
Height with Stand |
618.94 mm |
Width with Stand |
713.20 mm |
Depth with Stand |
215 mm |
Compressed Height with Stand |
468.94 mm |
Extended Height with Stand |
618.94 mm |
Weight (Approximate) |
6.52 kg |
Weight with Stand (Approximate) |
9.34 kg |
MISCELLANEOUS |
|
Package Contents |
UltraSharp 32 3840 x 2160 Thunderbolt Hub Monitor U3225QE Stand Drivers and Documentation Media QR Card Safety Information |
Cables Included |
Power Cable 1 x DisplayPort-DisplayPort Cable - 1.80 m 1 x USB Type-A to Type-C Upstream Cable 1.00 m 1 x Thunderbolt 4 passive cable - 1.00 m |
Energy Star |
Yes |
TCO Certified |
Yes |
Dell Display Manager Compatibility |
Yes |
Environmentally Friendly |
Yes |
Environmental Certification |
TCO Certified Edge |
Energy Efficiency Certification |
ENERGY STAR 8.0 |
Energy Efficiency Compliance |
Energy-related Products Directive Lot 5 (ErP Lot 5) |
Environmental Compliance |
Restriction of Hazardous Substances (RoHS) |
