Description
SPECIFICATIONS:
TECHNICAL INFORMATION |
|
Diagonal Viewing Size |
604.70 mm 23.80 inches |
Preset Display Area (H x V) |
527.04 mm x 296.46 mm 20.75" x 11.67" 156,246.27 mm2 (242.15 inches2) |
Panel Type |
IPS |
Display Screen Coating |
Anti-Glare with 3H hardness |
Maximum Preset Resolution |
1920 x 1080 at 120 Hz |
Viewing Angle |
178°vertical / 178°°horizontal |
Pixel Pitch |
0.2745 mm x 0.2745 mm |
Pixel Per Inch (PPI) |
92.53 |
Contrast Ratio |
1000 to 1 (typical) |
Aspect Ratio |
16:9 |
Backlight Technology |
LED Edgelight System |
Brightness |
250 cd/m2 (typical) |
Response Time |
8 ms (Normal) 5 ms (Fast) |
HDR Ready |
No |
Ambient Light Sensor |
Yes, auto brightness and colour temperature adjustmemt |
Colour Support |
16.7 million colours |
Colour Gamut |
100% sRGB, 100% BT.709, 85% DCI-P3, Delta E < 2 (average) (sRGB and BT.709) |
Interfaces |
1 x DisplayPort 1.4 (DRR for Microsoft Windows) (HDCP 1.4)7 1 x HDMI (HDCP 1.4)(supports up to FHD 1920 x 1080 120Hz TMDS as per specified in HDMI 1.4) 1 x DisplayPort 1.4 (Out) with MST (HDCP 1.4) 1 x USB Type-C upstream port (data only, SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) 2 x USB Type-A downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) 1 x audio line-out port
Quick Access: 1 x USB Type-C downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) with power charging (15W) 1 x USB Type-A downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) with BC1.2 power charging |
Adjustability |
Height, Tilt, Swivel, Pivot |
Height adjustable |
150 mm |
Tilt |
-5°/+21° |
Swivel |
-45°/+45° |
Pivot |
-90°/+90° |
PbP / PiP |
No |
Keyboard, Video and Mouse (KVM) |
No |
Daisy Chain Availability |
Yes |
Audio Output |
1 x Audio line-out |
Built-in Speaker |
No |
Security |
Security lock slot (cable lock sold separately) Anti-theft stand lock slot (to lock stand to monitor using screw) |
Compliant Standards |
ENERGY STAR certified monitor EPEAT registered where applicable. EPEAT registration varies by country. See www.epeat.net for registration status by country. RoHS-compliant TCO Certified & TCO Certified Edge BFR/PVC free monitor (excluding external cables) Arsenic-free glass and Mercury-free for the panel only |
Flat Panel Mount Interface |
VESA mounting holes (100 mm x 100 mm - behind attached VESA Cover) |
What's Included |
Monitor, Stand Riser, Stand Base, Quick setup guide, Safety, Environmental and Regulatory Information, Factory calibration report |
Cables Included |
1 x Power cable 1 x DisplayPort 1.4 cable - 1.8 m 1 x USB Type-A to USB Type-C Gen 2 cable - 1 m |
Voltage Required |
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A (typical) |
Power Consumption (On mode) |
13.7 W |
Power Consumption (Max) |
72.0 W |
Power Consumption Stand by |
0.5 W |
Power Consumption (Off Mode) |
0.3 W |
Dell Display Manager Compatibility |
Yes , Easy Arrange, Other key features |
Temperature Range |
Operating: 0°C to 40°C (32°F to 104°F) Non-operating: –20°C to 60°C (–4°F to 140°F) - Storage and Shipping |
Humidity Range |
Operating: 10% to 80% (non-condensing) Non-Operating: 5% to 90% (non-condensing) - Storage and Shipping |
Altitude |
Operating: 5000 m (16404 ft) max Non-Operating: 12192 (40000 ft) max |
PHYSICAL CHARACTERISTICS |
|
Height with stand (Compressed ~ Extended) |
364.00 mm ~ 496.53 mm |
Width with stand |
538.64 mm |
Depth with stand |
181.75 mm |
Height without stand |
311.21 mm |
Width without stand |
538.64 mm |
Depth without stand |
49.10 mm |
Weight (panel only - for VESA mount) |
3.52 kg |
Weight (with stand assembly and cables) |
5.38 kg |
Weight (with packaging) |
7.92 kg |
