SPECIFICATIONS:
AIRCRAFT |
|
Takeoff Weight |
Mavic 3 Pro: 958 g |
Dimensions |
Folded (without propellers): 231.1×98×95.4 mm (L×W×H) Unfolded (without propellers): 347.5×290.8×107.7 mm (L×W×H) |
Max Ascent Speed |
8 m/s |
Max Descent Speed |
6 m/s |
Max Horizontal Speed (at sea level, no wind) |
21 m/s |
Max Takeoff Altitude |
6000 m |
Max Flight Time |
43 minutes Measured in a controlled test environment. Specific test conditions are as follows: flying at a constant speed of 32.4 kph in a windless environment at sea level, with APAS off, AirSense off, camera parameters set to 1080p/24fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version. |
Max Hovering Time |
37 minutes Measured in a controlled test environment. Specific test conditions are as follows: hovering in a windless environment at sea level, with APAS off, AirSense off, camera parameters set to 1080p/24fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version. |
Max Flight Distance |
28 km The flight distance is different from the video transmission distance. The data was tested in a controlled environment, under the following specific test conditions: flying at a constant speed of 50.4 kph in a windless environment at sea level, with APAS off, AirSense off, camera parameters set to 1080p/24fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version. |
Max Wind Speed Resistance |
12 m/s |
Max Pitch Angle |
35° |
Operating Temperature |
-10° to 40° C (14° to 104° F) |
Global Navigation Satellite System |
GPS + Galileo + BeiDou |
Hovering Accuracy Range |
Vertical: ±0.1 m (with vision positioning) ±0.5 m (with satellite positioning)
Horizontal: ±0.3 m (with vision positioning) ±0.5 m (with satellite positioning) |
Internal Storage |
Mavic 3 Pro: 8 GB (approx. 7.9GB available space) |
Class |
C2 (EU) |
CAMERA |
|
Image Sensor |
Hasselblad Camera: 4/3 CMOS, Effective Pixels: 20 MP Medium Tele Camera: 1/1.3″ CMOS, Effective Pixels: 48 MP Tele Camera: 1/2″ CMOS, Effective Pixels: 12 MP |
Lens |
Hasselblad Camera FOV: 84° Format Equivalent: 24mm Aperture: f/2.8-f/11 Focus: 1 m to ∞
Medium Tele Camera FOV: 35° Format Equivalent: 70mm Aperture: f/2.8 Focus: 3 m to ∞
Tele Camera FOV: 15° Format Equivalent: 166mm Aperture: f/3.4 Focus: 3 m to ∞ |
ISO Range |
Video Normal and Slow Motion: 100-6400 (Normal) 400-1600 (D-Log) 100-1600 (D-Log M) 100-1600 (HLG) Night: 800-12800 (Normal)
Photo 100-6400 |
Shutter Speed |
Hasselblad Camera: 8-1/8000 s Medium Tele Camera: 2-1/8000 s Tele Camera: 2-1/8000 s |
Max Image Size |
Hasselblad Camera: 5280×3956 Medium Tele Camera: 8064×6048 Tele Camera: 4000×3000 |
Still Photography Modes |
Hasselblad Camera Single Shot: 20 MP Burst Shooting: 20 MP, 3/5/7 frames Automatic Exposure Bracketing (AEB): 20 MP, 3/5 frames at 0.7 EV step Timed: 20 MP, 2/3/5/7/10/15/20/30/60 s Medium Tele Camera Single Shot: 12 MP or 48 MP Burst Shooting: 12 MP or 48 MP, 3/5/7 frames Automatic Exposure Bracketing (AEB): 12 MP or 48 MP, 3/5 frames at 0.7 EV step Timed: 12 MP: 2/3/5/7/10/15/20/30/60 s 48 MP: 7/10/15/20/30/60 s Tele Camera Single Shot: 12 MP Burst Shooting: 12 MP, 3/5/7 frames Automatic Exposure Bracketing (AEB): 12 MP, 3/5 frames at 0.7 EV step Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s |
Photo Format |
JPEG/DNG (RAW) |
Video Resolution |
Hasselblad Camera Apple ProRes 422 HQ/422/422 LT 5.1K: 5120×2700@24/25/30/48/50fps DCI 4K: 4096×2160@24/25/30/48/50/60/120*fps 4K: 3840×2160@24/25/30/48/50/60/120*fps H.264/H.265 5.1K: 5120×2700@24/25/30/48/50fps DCI 4K: 4096×2160@24/25/30/48/50/60/120*fps 4K: 3840×2160@24/25/30/48/50/60/120*fps FHD: 1920×1080@24/25/30/48/50/60/120*/200*fps * Recording frame rates. The corresponding video plays as slow-motion video.
Medium Tele Camera Apple ProRes 422 HQ/422/422 LT 4K: 3840×2160@24/25/30/48/50/60fps H.264/H.265 4K: 3840×2160@24/25/30/48/50/60fps FHD: 1920×1080@24/25/30/48/50/60fps Tele Camera Apple ProRes 422 HQ/422/422 LT 4K: 3840×2160@24/25/30/48/50/60fps H.264/H.265 4K: 3840×2160@24/25/30/50/60fps FHD: 1920×1080@24/25/30/50/60fps
Only the Cine version supports ProRes recording. |
Video Format |
MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265) MOV (Apple ProRes 422 HQ/422/422 LT) Only the Cine version supports ProRes recording. |
Max Video Bitrate |
Hasselblad Camera: H.264/H.265: 200 Mbps ProRes 422 HQ: 3772 Mbps ProRes 422: 2514 Mbps ProRes 422 LT: 1750 Mbps
Medium Tele Camera: H.264/H.265: 160 Mbps ProRes 422 HQ: 1768 Mbps ProRes 422: 1178 Mbps ProRes 422 LT: 821 Mbps
Tele Camera: H.264/H.265: 160 Mbps ProRes 422 HQ: 1768 Mbps ProRes 422: 1178 Mbps ProRes 422 LT: 821 Mbps
Only the Cine version supports ProRes recording. |
Supported File System |
exFAT |
Color Mode and Sampling Method |
Hasselblad Camera Normal: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) 8-bit 4:2:0 (H.264/H.265) D-Log: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) 10-bit 4:2:0 (H.264/H.265) HLG/D-Log M: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) 10-bit 4:2:0 (H.265)
Medium Tele Camera Normal: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) 8-bit 4:2:0 (H.264/H.265) HLG/D-Log M: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) 10-bit 4:2:0 (H.265)
Tele Camera Normal: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) 8-bit 4:2:0 (H.264/H.265) HLG/D-Log M: 10-bit 4:2:2 (Apple ProRes 422 HQ/422/422 LT) 10-bit 4:2:0 (H.265)
Only the Cine version supports ProRes recording. |
|
Digital Zoom (only in Normal Video Mode and Explore Mode) |
Hasselblad Camera: 1-3x Medium Tele Camera: 3-7x Tele Camera: 7-28x |
GIMBAL |
|
Stabilization |
3-axis mechanical gimbal (tilt, roll, pan) |
Mechanical Range |
Tilt: -140° to 50° Roll: -50° to 50° Pan: -23° to 23° |
Controllable Range |
Tilt: -90° to 35° Pan: -5° to 5° |
Max Control Speed (tilt) |
100°/s |
Angular Vibration Range |
Hovering Without Wind: ±0.001° Normal Mode: ±0.003° Sport Mode: ±0.005° |
SENSING |
|
Sensing Type |
Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft |
Forward |
Measurement Range: 0.5-20 m Detection Range: 0.5-200 m Effective Sensing Speed: Flight Speed ≤ 15 m/s FOV: Horizontal 90°, Vertical 103° |
Backward |
Measurement Range: 0.5-16 m Effective Sensing Speed: Flight Speed ≤ 12 m/s FOV: Horizontal 90°, Vertical 103° |
Lateral |
Measurement Range: 0.5-25 m Effective Sensing Speed: Flight Speed ≤ 15 m/s FOV: Horizontal 90°, Vertical 85° |
Upward |
Measurement Range: 0.2-10 m Effective Sensing Speed: Flight Speed ≤ 6 m/s FOV: Front and Back 100°, Left and Right 90° |
Downward |
Measurement Range: 0.3-18 m Effective Sensing Speed: Flight Speed ≤ 6 m/s FOV: Front and Back 130°, Left and Right 160° |
Operating Environment |
Forward, Backward, Left, Right, and Upward: surfaces with discernible patterns and adequate lighting (lux > 15) Downward: surfaces with discernible patterns, diffuse reflectivity > 20% (e.g. walls, trees, people), and adequate lighting (lux > 15) |
VIDEO TRANSMISSION |
|
Video Transmission System |
O3+ |
Live View Quality |
Remote Controller: 1080p/30fps, 1080p/60fps |
Operating Frequency |
2.400-2.4835 GHz 5.725-5.850 GHz |
Transmitter Power (EIRP) |
2.4 GHz: < 33 dBm (FCC) < 20 dBm (CE/SRRC/MIC)
5.8 GHz: < 33 dBm (FCC) < 30 dBm (SRRC) < 14 dBm (CE) |
|
Max Transmission Distance (unobstructed, free of interference) |
FCC: 15 km CE: 8 km SRRC: 8 km MIC: 8 km Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. During your flight, please pay attention to RTH reminders in the DJI Fly app. |
|
Max Transmission Distance (unobstructed, with interference) |
Strong Interference: Urban landscape, approx. 1.5-3 km Medium Interference: Suburban landscape, approx. 3-9 km Low Interference: Suburb/seaside, approx. 9-15 km Data tested under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual transmission distance. |
|
Max Transmission Distance (obstructed, with interference) |
Low Interference and Obstructed by Buildings: approx. 0-0.5 km Low Interference and Obstructed by Trees: approx. 0.5-3 km Data tested under FCC standard in environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance. |
Max Download Speed |
O3+: 5.5 MB/s (with DJI RC-N1 Remote Controller) 15 MB/s (with DJI RC Pro) 5.5 MB/s (with DJI RC) Wi-Fi 6: 80 MB/s* * Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz, with footage saved to the internal storage. Download speeds may vary depending on the actual conditions. |
Lowest Latency |
130 ms (with DJI RC-N1 Remote Controller) 120 ms (with DJI RC Pro) 130 ms (with DJI RC) Depending on the actual environment and mobile device. |
Antenna |
4 antennas, 2T4R |
BATTERY |
|
Capacity |
5000 mAh |
Weight |
335.5 g |
Nominal Voltage |
15.4 V |
Max Charging Voltage |
17.6 V |
Type |
Li-ion 4S |
Energy |
77 Wh |
Charging Temperature |
5° to 40° C (41° to 104° F) |
Charging Time |
Approx. 96 minutes Use the included data cable of the DJI 65W Portable Charger.
Approx. 70 minutes Use the DJI 100W USB-C Power Adapter and DJI Mavic 3 Series 100W Battery Charging Hub. |
