Description
SPECIFICATIONS:
Product length/depth |
288 mm |
Product height |
148 mm |
Product width |
100 mm |
Product weight |
5.29 kg |
Secondary frequency - max |
60 Hz |
Wattage |
480 W |
Form factor |
Tower |
Includes network card |
No |
Input connection |
AU plug |
Input voltage - min |
140 V |
Output voltage - max |
257 V |
Secondary frequency - min |
50 Hz |
Software compatibility |
Eaton UPS Companion (enables safe system shutdown, energy usage metering and configuration of UPS settings) |
Battery type |
Sealed, lead-acid |
Efficiency |
95 |
Special features |
Automatic Voltage Regulation (AVR) Saves space with a compact tower design HID-compliant USB port, for automatic integration with major operating systems (Windows/Mac OS/Linux) |
Construction type |
Free standing model |
Output voltage - min |
195 V |
Colour |
Black |
Extended battery capability |
No |
Output voltage range |
195-257 V |
Topology |
Line-interactive |
Surge protection |
Yes |
Input nominal voltage |
240V |
Input frequency range |
45-65 Hz |
Internal bypass |
No |
Input voltage - max |
300 V |
Voltage type |
AC |
Phase (output) |
1 |
Battery management |
Automatic battery test, deep-discharge protection, cold-start capable |
Auto shutdown function |
Yes |
Number of outputs C13 |
2 |
Operating temperature - min |
0 °C |
VA rating |
900 VA |
Potential free switch contact |
No |
Receptacle |
(2) AU |
Phase (input) |
1 |
Package contents |
Quick start Safety instructions |
Noise level |
<25 dB at 1 meter |
Feed type |
1 |
Runtime graph |
View runtime graph |
User interface |
LEDs |
Battery quantity |
1 |
Operating temperature - max |
40 °C |
Voltage |
240V |
Hot swap power |
No |
Temperature range |
0° to 40°C (32° to 104°F) |
Ethernet interface |
No |
Communication |
USB port (HID compliant) |
Relative humidity |
0-85% non-condensing |
Output apparent power |
900 VA |
Rack mounting kit |
No |
Output frequency |
50/60 Hz |
Type of interface |
USB |
Primary requency - min |
45 Hz |
Battery rating |
12 V / 9 Ah |
Type |
UPS |
Output nominal voltage |
240V |
Input voltage range |
140-300 V |
Nominal frequency |
50/60 Hz |
Primary frequency - max |
65 Hz |
