Description
Unity power factor on all models (Gen1 is 0.9 pf)
New advanced LCD control display
New step by step commissioning wizard
Remote firmware update on the UPS via M2 card
SPECIFICATIONS:
BATTERY: |
ABM® & Temperature compensated charging method (user selectable), Automatic battery test, deep discharge protection, automatic recognition of external battery units |
COMMUNICATION/MANAGEMENT: |
1 slot for NMC Minislot card or NMC ModBus/JBus or MC Contacts/Serial |
DEVICE TYPE: |
UPS |
FREQUENCY: |
47 to 70 Hz (50 Hz system), 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode |
INPUT CONNECTION: |
(1) IEC-320-C14 |
INPUT VOLTAGE: |
160V-294V (adjustable to 150V-294V) |
MISC.: |
Tower/Rack 2U |
OUTPUT RECEPTACLES: |
(8) IEC-320-C13 |
OUTPUT VOLTAGE: |
230 V (+6/-10 %) (Adjustable to 200V / 208V / 220V / 230V / 240V) |
POWER RATING/CAPACITY: |
2000/1800 |
SERIES: |
5PX Gen2 |
