Description
SPECIFICATIONS:
LIQUID COOLER - FAN |
|
Dimensions |
120 x 120 x 25 mm |
Speed |
800 – 1800 RPM±10% |
Noise Level |
11 - 29 dBA |
Air Flow |
69 CFM |
Air Pressure |
2.7 mmH2O |
Bearing |
Hydraulic |
Rated Voltage |
12 V (Fan) / 5V(LED) |
Connector |
8 pin |
Support PWM Control |
No |
LIQUID COOLER |
|
Radiator Dimensions |
394 x 119 x 27 mm |
Tube Material |
Teflon |
Base Plate Material |
Copper |
Radiator Material |
Aluminum |
Sleeved Tube |
Yes |
Pump Rated Voltage |
12 V (Pump) / 5V(LED) |
Pump Connector |
3 Pin |
Compatibility |
LGA2066 / 2011-v3 / 2011 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1 / TR4 |
TDP |
250W ±10% |
Support Motherboard RGB Sync Connectors |
5V 3-pin addressable (digital) RGB header Only |
LIQUID COOLER - REMOTE CONTROL |
|
Selectable Fan Speeds |
Yes |
Selectable Light Speeds |
Yes |
Selectable Brightness |
Yes |
LIQUID COOLER - CONTROL BOX |
|
Model |
AEOLUS Box |
Dimensions |
92 x 46 x 13 mm |
Power Connector |
SATA |
Support LED type |
5V 3-pin Addressable (Digital) LED |
Support Daisy Chain |
Yes |
Built-In Magnet |
Yes |
