Description
SPECIFICATIONS:
Panel Size (diagonal) |
31.5" OLED |
Display Viewing Area (HxV) |
699.48 x 394.73 mm |
Panel Backlight/ Type |
OLED |
Display Surface(non-glare/ glare) |
Anti-Reflection |
Color Saturation |
99% DCI-P3 |
True Resolution |
3840 x 2160 (UHD) |
Pixel Pitch |
0.181(H) x 0.181(V) mm |
Brightness |
250 cd/m2 (Typ, SDR APL 100%); 1000 nits (Typ, HDR APL 3%) |
Contrast Ratio |
1.5M:1 |
Viewing Angle |
178°(H)/178°(V) |
Display Colors |
10bit (1.07B) |
Response Time |
0.03ms GTG |
Refresh Rate |
165Hz |
HDR |
VESA DisplayHDR True Black 400 |
VESA Certified ClearMR |
ClearMR 9000 |
Flicker-free |
Yes |
Factory Calibration |
Yes, △E ≤ 2 |
Connectivity |
2 x HDMI 2.1 1 x Displayport 1.4 1 x USB Type-C (Alternate Mode; Upstream port; Power Delivery up to 18W) 2 x USB 3.2 Downstream ports 1 x USB 3.2 Upstream port 1 x Earphone Jack |
Earphone Jack |
Yes |
Speaker |
5W x 2 |
Unique Features |
Tactical Switch OSD Sidekick * Black Equalizer 2.0 Dashboard Crosshair Timer Counter Night Vision Eagle Eye PiP/PbP Auto-Update KVM 6 axis Color Control Apply Picture Mode HDMI-CEC |
Power Type |
Power Board Build-in |
Power Consumption |
54W ** |
Power Saving Mode |
<0.5W |
Power Off Mode |
<0.3W |
Voltage |
AC 100-240V ~ 50/60Hz |
Tilt(angle) |
-5°~+21° |
Swivel(angle) |
±15° |
Pivot(angle/direction) |
-0°~+90°(Counter-Clockwise) |
Height Adjustment (mm) |
130 mm |
VESA Wall Mounting(mm) |
100*100 mm |
Kensington lock |
Yes |
Phys. Dimension with Stand (WxHxD) |
718.3 x 610.45 x 240 mm |
Phys. Dimension w/o stand (WxHxD) |
718.3 x 417.5 x 64.2 mm |
Box Dimension (WxHxD) |
980 x 545 x 168 mm |
Net Weight with stand (Esti.) |
8.9 ± 0.5 kg |
Net Weight without stand (Esti.) |
6.8 ± 0.5 kg |
Gross Weight (Esti.) |
13.52 ± 0.3 kg |
Accessories |
Power cable/HDMI 2.1 cable/DP cable/USB cable/QSG/Warranty card/Color calibration test report |
Note |
*To enable OSD Sidekick, it requires connection between PC and monitor with USB (A-Male to B-Male) cable. **The test condition follows CEC standards. |
