HTC VIVE XR Elite Virtual Reality Headset

Resolution

1920 x 1920 pixels per eye (3840 x 1920 pixels combined)

Headset tracking

6DoF inside-out tracking

Up to 10 x 10 m play space recommended

Refresh rate

90 Hz

Field of view

Up to 110 degrees

Audio

Dual microphones for echo cancellation

Embedded speakers

Inputs

Dual integrated microphones

Volume button

Headset button

Processor

Qualcomm® Snapdragon™ XR2

Storage and memory

128 GB ROM

12 GB RAM

Connections

USB 3.2 Gen-1 Type-C peripheral port x 1

USB 3.2 Gen-1 Type-C power port x 1

Bluetooth 5.2 + BLE

Wi-Fi 6 + 6E

Sensors

Tracking cameras x 4

16 MP RGB camera

Depth sensor

G-sensor

Gyroscope

Proximity sensor

Ergonomics

Perfect weight balance provides comfortable long-session use

Ergonomically curved battery module mounted in the rear as counterweight

Magnetically-attached front gasket

Eye comfort adjustment accommodating IPD range of 54 to 73 mm

Battery

24.32 Wh battery cradle that is removeable and hot-swappable

Offers battery life of up to 2 hours

Lightweight and quickly rechargeable with Lithium-Polymer Gel chemistry

Designed and molded with an ergonomic curve

Microphone

Dual integrated microphones

IPD

Accommodates range of 54–73 mm

CONTROLLER

Sensors

Hall sensors on Trigger and Grip buttons

Capacitive sensors on Trigger, Joystick, and Thumb-rest area

G-Sensor

Gyroscope

Input

Ergonomic Grip button

Analog Trigger button

A and B / X and Y buttons

System / Menu buttons

Joystick

Battery

Controller battery life of up to 15 hours*

Integrated rechargeable battery (charged via USB-C)

* All battery claim results will vary. Battery life and charge cycles vary by use.

TRACKED AREA REQUIREMENTS

Standing / Seated

Both available

Room-scale

Up to 10 x 10 m play area recommended

Minimum play area is 1.5 x 1.5 m (standing)

OTHERS

Packaging Contents

VIVE XR Elite headset

Battery cradle

Controller (L)

Controller (R)

Lanyards x 2

Microfiber pouch

Top strap

USB Type-C to Type-C cable

USB Type-A to Type-C cable x 2

Lens protection card

Documentation (QSG / safety guide / warranty card)
