SPECIFICATIONS:
CAMERA |
|
Video System |
4K/60fps, 4K/59.97fps, 4K/50fps, 4K/30fps, 4K/25fps, 4K/29.97fps, 1080P/60fps, 1080P/50fps, 1080I/60fps, 1080I/50fp, 1080P/30fps, 1080P/59.94fps, 1080I/59.94fps, 1080P/29.97fps, 720P/60fps, 720P59.94fps |
Sensor |
1/2.8”, CMOS, Effective Pixel: 840M |
Lens |
20x, f=6.25mm ~ 125mm , F1.84 ~ F3.72 |
Digital Zoom |
16X |
Minimal Illumination |
0.5Lux @ (F1.8, AGC ON) |
Shutter |
1/30s ~ 1/10000s |
White Balance |
Auto, Indoor, Outdoor, One Push, Manual, Specified color temperature |
Digital Noise Reduction |
3D Digital Noise Reduction |
USB FEATURED |
|
Operating System |
Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android |
Color System / Compression |
YUY2 / H.264 / MJPEG |
Video Format |
“YUY2 :Max 1080P/30fps H.264 AVC: Max 2160P/60fps H.264 SVC: Max 2160P/60fps MJPEG: max 4K/30fps” |
Audio on USB |
Support |
USB Video Communication Protocol |
UVC 1.1~1.5 |
NETWORK FEATURES |
|
Video Compression |
H.265/H.264/MJPEG |
Video Stream |
First Stream, Second Stream |
Main Stream Resolution |
3840×2160, 1920×1080, 1280×720, 1024×576 etc |
Sub Stream Resolution |
720×576, 720×480, 320×240 etc (*) |
Video Bit Rate |
32kbps~102400kbps |
Frame Rate |
50Hz: 1fps~50fps, 60Hz:1fps~60fps |
Audio Compression |
AAC、G711 |
Audio Bit Rate |
48Kbps, 64Kbps, 96Kbps, 128Kbps |
