Description
SPECIFICATIONS:
CUDA Cores |
8960 |
Boost Clock (MHz) |
2452MHz |
Base Clock (MHz) |
2295MHz |
Minimum System Power Requirement (W) |
750W |
Supplementary Power Connectors |
2x PCIe 8-pin cables (adapter in box) OR 300 W or greater PCIe Gen 5 cable |
Memory Clock |
28Gbps |
Standard Memory Config |
16GB |
Memory Interface |
GDDR7 |
Memory Interface Width |
256-bit |
Memory Bandwidth (GB/sec) |
896 GB/sec |
Real-Time Ray Tracing |
Yes |
Ray Tracing Cores |
4th Generation, 133 TFLOPS |
Tensor Cores |
5th Generation, 1406 AI TOPS |
NVIDIA Architecture |
Blackwell |
Microsoft DirectX |
12 Ultimate |
NVIDIA DLSS |
4 |
NVIDIA Ansel |
Yes |
NVIDIA FreeStyle |
Yes |
Bus Support |
PCI Express Gen 5 |
NVIDIA ShadowPlay |
Yes |
OS Certification |
Windows 11 / 10, Linux, FreeBSDx86 |
NVIDIA Highlights |
Yes |
NVIDIA G-SYNC™-Ready |
Yes |
Game Ready Drivers |
Yes |
NVIDIA Studio Drivers |
Yes |
NVIDIA GPU Boost™ |
Yes |
Vulkan API |
1.4 |
OpenGL |
4.6 |
NVIDIA Encoder |
2x Ninth Generation |
NVIDIA Decoder |
1x Sixth Generation |
Length |
300mm |
Height |
116mm |
Width |
41mm |
Multi Monitor |
up to 4 |
Maxmium Digital Resolution |
4K at 480Hz or 8K at 165Hz with DSC |
HDCP |
2.3 |
Standard Display Connectors |
3x DisplayPort 2.1b, 1x HDMI 2.1b |
