Description
SPECIFICATIONS:
ESSENTIALS |
|
Product Collection |
Intel® Arc™ B-Series Graphics |
Model Number |
B580 |
Code Name |
Products formerly Battlemage |
Microarchitecture |
Xe2 |
Lithography Type |
TSMC N5 |
Vertical Segment |
Desktop |
Embedded Options Available |
No |
GPU SPECIFICATIONS |
|
Xe-cores |
20 |
Render Slices |
5 |
Ray Tracing Units |
20 |
Intel® Xe Matrix Extensions (Intel® XMX) Engines |
160 |
Xe Vector Engines |
160 |
Graphics Clock |
2670 MHz |
GPU Peak TOPS (Int8) |
233 |
TBP |
190 W |
PCI Express Configurations |
PCI Express 4.0 x8 |
Device ID |
0xE20B |
MEMORY SPECIFICATIONS |
|
Memory |
12 GB GDDR6 |
Graphics Memory Interface |
192 bit |
Graphics Memory Bandwidth |
456 GB/s |
Graphics Memory Speed |
19 Gbps |
I/O SPECIFICATIONS |
|
# of Displays Supported |
4 |
Graphics Output |
HDMI* 2.1, DP2.1 up to UHBR 13.5, DP2.1 up to UHBR 10 |
HDMI Variable Refresh Rate (VRR) |
Yes |
VESA Adaptive Sync |
Yes |
Media Profiles |
HDR10, HDR10+ Gaming, Dolby Vision |
Max Resolution (HDMI) |
7680 x 4320@120Hz |
Max Resolution (DP) |
7680 x 4320@60Hz |
FEATURES |
|
H.264 Hardware Encode/Decode |
Yes |
H.265 (HEVC) Hardware Encode/Decode |
Yes |
AV1 Encode/Decode |
Yes |
VP9 Bitstream & Decoding |
Yes |
SUPPORTED TECHNOLOGIES |
|
Ray Tracing |
Yes |
oneAPI Support |
Yes |
OpenVINO™ Support |
Yes |
DirectX* Support |
DirectX 12 Ultimate |
Vulkan* Support |
1.3 |
OpenGL* Support |
Up to 4.6 |
OpenCL* Support |
3.0 |
Multi-Format Codec Engines |
2 |
Intel® Extension for PyTorch* (IPEX) Support |
Yes |
Intel® Xe Super Sampling (XeSS) Support |
Yes |
INTEL REFERENCE CARD ATTRIBUTES |
|
Dimensions (Length x Width) |
272 x 115 mm |
Slots |
2 |
Weight |
779 G |
Minimum Power Supply Unit |
600 W |
Power Connectors |
1 x 8-pin |
