Description
SPECIFICATIONS:
ESSENTIALS |
|
Product Collection |
Intel® Core™ Ultra Processors (Series 2) |
Code Name |
Products formerly Arrow Lake |
Vertical Segment |
Desktop |
Processor Number |
265F |
Overall Peak TOPS (Int8) |
25 |
CPU SPECIFICATIONS |
|
Total Cores |
20 |
# of Performance-cores |
8 |
# of Efficient-cores |
12 |
Total Threads |
20 |
Max Turbo Frequency |
5.3 GHz |
Intel® Turbo Boost Max Technology 3.0 Frequency |
5.3 GHz |
Performance-core Max Turbo Frequency |
5.2 GHz |
Efficient-core Max Turbo Frequency |
4.6 GHz |
Performance-core Base Frequency |
2.4 GHz |
Efficient-core Base Frequency |
1.8 GHz |
Cache |
30 MB Intel® Smart Cache |
Total L2 Cache |
36 MB |
Processor Base Power |
65 W |
Maximum Turbo Power |
182 W |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
AI Software Frameworks Supported by CPU |
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
CPU Lithography |
TSMC N3B |
MEMORY SPECIFICATIONS |
|
Max Memory Size (dependent on memory type) |
192 GB |
Memory Types |
Up to DDR5 6400 MT/s |
Max # of Memory Channels |
2 |
ECC Memory Supported |
Yes |
NPU SPECIFICATIONS |
|
NPU Name |
Intel® AI Boost |
NPU Peak TOPS (Int8) |
13 |
Sparsity Support |
Yes |
Windows Studio Effects Support |
Yes |
AI Software Frameworks Supported by NPU |
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
EXPANSION OPTIONS |
|
Direct Media Interface (DMI) Revision |
4 |
Max # of DMI Lanes |
8 |
Intel® Thunderbolt™ 4 |
Yes |
Scalability |
1S Only |
PCI Express Revision |
5.0 and 4.0 |
PCI Express Configurations |
Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 |
Max # of PCI Express Lanes |
24 |
PACKAGE SPECIFICATIONS |
|
Sockets Supported |
FCLGA1851 |
Thermal Solution Specification |
PCG 2022C |
Max Operating Temperature |
105 °C |
ADVANCED TECHNOLOGIES |
|
Intel® Volume Management Device (VMD) |
Yes |
Intel® Gaussian & Neural Accelerator |
3.5 |
Intel® Thread Director |
Yes |
Intel® Speed Shift Technology |
Yes |
Intel® Turbo Boost Max Technology 3.0 |
Yes |
Intel® Turbo Boost Technology |
2.0 |
Intel® 64 |
Yes |
Instruction Set |
64-bit |
Instruction Set Extensions |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
Idle States |
Yes |
Enhanced Intel SpeedStep® Technology |
Yes |
Thermal Monitoring Technologies |
Yes |
SECURITY & RELIABILITY |
|
Intel vPro® Eligibility |
Intel vPro® Enterprise |
Intel® Threat Detection Technology (TDT) |
Yes |
Intel® Active Management Technology (AMT) |
Yes |
Intel® Standard Manageability (ISM) |
Yes |
Intel® Remote Platform Erase (RPE) |
Yes |
Intel® One-Click Recovery |
Yes |
Intel® Control-Flow Enforcement Technology |
Yes |
Intel® Total Memory Encryption - Multi Key |
Yes |
Intel® AES New Instructions |
Yes |
Secure Key |
Yes |
Intel® Trusted Execution Technology |
Yes |
Execute Disable Bit |
Yes |
Intel® OS Guard |
Yes |
Intel® Boot Guard |
Yes |
Mode-based Execute Control (MBEC) |
Yes |
Intel® Stable IT Platform Program (SIPP) |
Yes |
Intel® Virtualization Technology with Redirect Protection (VT-rp) |
Yes |
Intel® Virtualization Technology (VT-x) |
Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) |
Yes |
Intel® VT-x with Extended Page Tables (EPT) |
Yes |
