Description
SPECIFICATIONS:
ESSENTIALS |
|
Product Collection |
12th Generation Intel® Core™ i7 Processors |
Code Name |
Products formerly Alder Lake |
Vertical Segment |
Desktop |
Processor Number |
i7-12700K |
Lithography |
Intel 7 |
CPU SPECIFICATIONS |
|
Total Cores |
12 |
# of Performance-cores |
8 |
# of Efficient-cores |
4 |
Total Threads |
20 |
Max Turbo Frequency |
5.00 GHz |
Intel® Turbo Boost Max Technology 3.0 Frequency* |
5.00 GHz |
Performance-core Max Turbo Frequency |
4.90 GHz |
Efficient-core Max Turbo Frequency |
3.80 GHz |
Performance-core Base Frequency |
3.60 GHz |
Efficient-core Base Frequency |
2.70 GHz |
Cache |
25 MB Intel® Smart Cache |
Total L2 Cache |
12 MB |
Processor Base Power |
125 W |
Maximum Turbo Power |
190 W |
MEMORY SPECIFICATIONS |
|
Max Memory Size (dependent on memory type) |
128 GB |
Memory Types |
Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
Max # of Memory Channels |
2 |
Max Memory Bandwidth |
76.8 GB/s |
PROCESSOR GRAPHICS |
|
Processor Graphics* |
Intel® UHD Graphics 770 |
Graphics Base Frequency |
300 MHz |
Graphics Max Dynamic Frequency |
1.50 GHz |
Graphics Output |
eDP 1.4b, DP 1.4a, HDMI 2.1 |
Execution Units |
32 |
Max Resolution (HDMI)* |
4096 x 2160 @ 60Hz |
Max Resolution (DP)* |
7680 x 4320 @ 60Hz |
Max Resolution (eDP - Integrated Flat Panel)* |
5120 x 3200 @ 120Hz |
DirectX Support |
12 |
OpenGL Support |
4.5 |
Multi-Format Codec Engines |
2 |
Intel® Quick Sync Video |
Yes |
Intel® Clear Video HD Technology |
Yes |
# of Displays Supported* |
4 |
Device ID |
0x4680 |
OpenCL Support |
2.1 |
EXPANSION OPTIONS |
|
Direct Media Interface (DMI) Revision |
4.0 |
Max # of DMI Lanes |
8 |
Scalability |
1S Only |
PCI Express Revision |
5.0 and 4.0 |
PCI Express Configurations* |
Up to 1x16+4, 2x8+4 |
Max # of PCI Express Lanes |
20 |
PACKAGE SPECIFICATIONS |
|
Max CPU Configuration |
1 |
Thermal Solution Specification |
PCG 2020A |
T JUNCTION |
100°C |
Package Size |
45.0 mm x 37.5 mm |
ADVANCED TECHNOLOGIES |
|
Intel® Gaussian & Neural Accelerator |
3.0 |
Intel® Thread Director |
Yes |
Intel® Deep Learning Boost (Intel® DL Boost) |
Yes |
Intel® Optane™ Memory Supported* |
Yes |
Intel® Speed Shift Technology |
Yes |
Intel® Turbo Boost Max Technology 3.0* |
Yes |
Intel® Turbo Boost Technology* |
2.0 |
Intel® Hyper-Threading Technology* |
Yes |
Intel® Virtualization Technology (VT-x)* |
Yes |
Intel® Virtualization Technology for Directed I/O (VT-d)* |
Yes |
Intel® VT-x with Extended Page Tables (EPT)* |
Yes |
Intel® 64* |
Yes |
Instruction Set |
64-bit |
Instruction Set Extensions |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
Idle States |
Yes |
Enhanced Intel SpeedStep® Technology |
Yes |
Thermal Monitoring Technologies |
Yes |
Intel® Volume Management Device (VMD) |
Yes |
SECURITY & RELIABILITY |
|
Intel® AES New Instructions |
Yes |
Secure Key |
Yes |
Intel® OS Guard |
Yes |
Execute Disable Bit* |
Yes |
Intel® Boot Guard |
Yes |
Mode-based Execute Control (MBE) |
Yes |
Intel® Control-Flow Enforcement Technology |
Yes |
