Intel NUC Pro NUC12WSHi3 Barebone Kit - 12th Gen Core i3

Product Collection

Intel® NUC Kit with 12th Generation Intel® Core™ Processors

Code Name

Products formerly Wall Street Canyon

Supported Operating Systems

Windows 11 Home, Windows 11 Pro, Windows 10 Home, Windows 10 IoT Enterprise, Windows 10 Pro, Red Hat Linux, Ubuntu 20.04 LTS (not included)

Board Number

NUC12WSBi3

Board Form Factor

UCFF (4" x 4")

Socket

Soldered-down BGA

Internal Drive Form Factor

M.2 and 2.5" Drive

# of Internal Drives Supported

3

TDP

20 W

DC Input Voltage Supported

12-20 VDC

Processor Included

Intel® Core™ i3-1220P Processor (12M Cache, up to 4.40 GHz)

# of Cores

10

# of Threads

12

Lithography

Intel 7

Max Turbo Frequency

4.40 GHz

MEMORY & STORAGE

Max Memory Size (dependent on memory type)

64 GB (not included)

Memory Types

DDR4-3200 1.2V SODIMMs

Max # of Memory Channels

2

Max # of DIMMs

2

ECC Memory Supported*

No

PROCESSOR GRAPHICS

Integrated Graphics*

Yes

Graphics Output

Dual HDMI 2.0b w/HDMI CEC, Dual DP 1.4a via Type C

# of Displays Supported*

4

EXPANSION OPTIONS

PCI Express Revision

Gen 4 (m.2 22x80 slot); Gen 3 (otherwise)

PCI Express Configurations*

PCIe x4 Gen 4: M.2 22x80 (key M)

PCIe x1 Gen 3: M.2 22x42 (key B)

PCIe x1: M.2 22x30 (key E)

M.2 Card Slot (wireless)

22x30 (E)

M.2 Card Slot (storage)

22x80 NVMe (M); 22x42 SATA (B)

CHASSIS FEATURES AND SIZE

Chassis Dimensions

117 x 112 x 54 mm

Chassis Features

Kensington lock with base security, 2.5” drive bay (15mm SATA), VESA mounting plate included

I/O SPECIFICATIONS

# of USB Ports

4

USB Configuration

Front: 2x USB 3.2

Rear: 2x USB 4 (type C), 1x USB 3.2, 1x USB 2.0

Internal: 1x USB 3.2 on m.2 22x42 (pins), 2x USB 2.0 (headers)

Total # of SATA Ports

1

Serial Port via Internal Header

No

Audio (back channel + front channel)

Front panel: 3.5mm headphone/mic jack

Integrated LAN

Intel® Ethernet Controller i225-V

Integrated Wireless*

Intel® Wi-Fi 6E AX211(Gig+)

Integrated Bluetooth

Yes

# of Thunderbolt™ Ports

2x Thunderbolt™ 4

ADVANCED TECHNOLOGIES

Intel® Optane™ Memory Supported*

No

Intel® Virtualization Technology for Directed I/O (VT-d)*

Yes

Intel® ME Firmware Version

16

Intel® HD Audio Technology

Yes

Intel® Virtualization Technology (VT-x)*

Yes

Intel® Platform Trust Technology (Intel® PTT)

Yes

Intel® AES New Instructions

Yes
