Description
Product parameters:
Model: k32
Photosensitive film: Jerry AC5225C+GC1054 (1/4 ")
Maximum effective pixel: 1920 (H) x 1080 (V);
Sensitivity: 600mV/Lux sec
Output image format: MJPEG/YUV2 (YUYV)
Camera board assembly technology: BGA SMT (ROSH)
Focusing: fixed
Object distance: 5CM-100M
Center clarity: 600LW/PH (Center)
Signal to noise ratio: 34dB
Dynamic range: 72.5dB
Sensitivity: 0.65V/ lux-sec@550nm
Supported resolution and frame rate (YUY2): 640x480:25 frames 640x360:30 frames
Supported resolution and frame rate (MJPEG default): 1280x720:30 frames 640x480:30 frames
Minimum illumination: 0.5lux
Shutter type: Electronic rolling shutter/Frame exposure
Interface type: USB2.0 High Speed
Automatic exposure control AEC: support
Automatic white balance AEB: supported
Automatic gain control AGC: support
Adjustable parameters: brightness, contrast, color saturation, tone clarity, gamma white balance, backlight contrast, exposure
Lens specification: 115 °
Lamp board power supply interface: supports 2P-2.0mm sockets
Power supply and interface: USB BUS POWER 4P-2.0mm socket
Voltage: DC5V
Current: 126mA
Size: Compatible with 30x25mm
Storage temperature: -20 ° C to 70 ° C
Working temperature: 0 ° C to 60 ° C
USB cable: 1.5M in stock
Working humidity: 15% -85%
System support: Win XP/Vista/Win7/Win8/WIN10/Linux with UVC (above linux-2.6.26)
MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC
