Description
SPECIFICATIONS:
Connection technology |
USB-C Alt Mode |
Driverless |
Yes |
Number of Screen Outputs |
3 |
Video ports |
DisplayPort++, HDMI, VGA |
Maximum resolution |
4K |
Power delivery |
100W |
Operating system(s) |
Windows |
Number of USB ports |
5 |
USB fast charging |
Yes |
Docking station family |
The Task Master |
DockWorks |
Yes (for Windows only) |
Best For |
USB-C Laptops & Ultrabooks that support Power Delivery and Monitors that support up to 4K |
Compatibility |
Windows 10 or above |
Card Reader |
SD Cards and Micro SD card slots (UHS-I, SD3.0) |
USB-A ports |
4 x: (2) USB 3.2 Gen2 (front) with 5V/0.9A (2) USB 2.0 (back) |
USB-C ports |
1 x USB-C 3.2 Gen2 (front) with 5V/1.5A charging |
Audio |
1 x 3.5mm Combo Microphone & Headphone Port (front) |
Data transfer speeds |
Supports up to 10Gbps data transfer speed |
Ethernet Speed (Mbps) |
10, 100, 1000 Actual Ethernet speeds may vary depending on, but not limited to, Internet bandwidth, Ethernet cables, network switches, and the hardware and firmware performance of the host computer. |
Maximum resolution supported |
Minimum Resolution (DP1.2/HBR2): Single 4K @ 30Hz Dual 1080p @ 60Hz Triple 1600x900 @ 60Hz // Maximum Resolution (DP1.4/HBR3): Single 4K @ 60Hz Dual 4K @ 60Hz Triple 1080p @ 60Hz |
Plug & play |
Plug & play installation without need for drivers or downloads |
System requirements |
Host device must support Power Delivery and DisplayPort Alt Mode over USB-C |
USB-C Power Delivery |
Supports USB-C PD 3.0 (100W of laptop charging) |
Video output |
1 x DisplayPort++ v1.4, 1 x VGA, 2 x HDMI v2.0 |
4K support |
Yes |
