Description
SPECIFICATIONS:
Connection technology |
USB-C Alt Mode |
Driverless |
Yes |
Video ports |
DisplayPort++, HDMI |
Maximum resolution |
4K |
Power delivery |
85W |
Operating system(s) |
Windows |
USB fast charging |
No |
Docking station family |
The Task Master |
Best For |
USB-C Laptops & Ultrabooks that support Power Delivery and Monitors that support up to dual 4K |
Compatibility |
Windows 10 or above |
USB-C ports |
1 x USB-C 3.2 Gen2 (front) with 5V/1.5A charging |
Audio |
1 x 3.5mm Combo Microphone & Headphone Port (front) |
Data transfer speeds |
Supports up to 10Gbps data transfer speed |
Ethernet Speed (Mbps) |
10, 100, 1000 Actual Ethernet speeds may vary depending on, but not limited to, Internet bandwidth, Ethernet cables, network switches, and the hardware and firmware performance of the host computer. |
Maximum resolution supported |
Minimum Resolution (DP1.2/HBR2): Single 4K @ 30Hz Dual 1080p @ 60Hz Triple 1080p @ 30Hz // Maximum Resolution (DP1.4/HBR3 *DSC On): Single and Dual 4K @ 60Hz*, Triple 1080p @ 60Hz |
Plug & play |
Plug & play installation without need for drivers or downloads |
System requirements |
Host device must support Power Delivery and DisplayPort Alt Mode over USB-C |
USB-C Power Delivery |
Supports USB-C PD 3.0 (85W of laptop charging) |
Video output |
1 x HDMI v2.0, 2 x DisplayPort++ v1.4 |
4K support |
Yes |
