Description
SPECIFICATIONS:
Number of Keys |
87 (80%) |
Switches |
Gateron low-profile mechanical - Brown |
Switch Face |
North-facing |
Number of Multimedia Keys |
12 |
Frame Material |
ABS+Aluminum frame |
Keycap Material |
Low-profile double-shot PBT |
Layout |
ANSI |
Polling Rate (2.4GHz and Wired Mode) |
1000Hz |
Polling Rate (BT Mode) |
90Hz |
N-Key Rollover (NKRO) |
Yes for both wireless and wired modes |
Backlit |
22 types of RGB backlight options plus endless possibilities |
Battery |
2000 mAh rechargeable li-polymer battery |
Connection |
2.4 GHz / Bluetooth / Type-C wired |
Bluetooth version |
5.1 |
Bluetooth Device Name |
Keychron K1 Max |
Compatible System |
macOS / Windows / Linux |
Dimension |
346 x 118.5 mm (13.62 x 4.66") |
Weight |
608 g / 1.34 lbs |
Height without keycap (front) |
7.72 mm (0.3") |
Height without keycap (rear) |
14.7 mm (0.58") |
Height incl. keycap (front) |
18.2 mm (0.72") |
Height incl. keycap (rear) |
24.1 mm (0.95") |
Typing Angle |
3.37º, 4.2º and 6.7º |
MCU |
ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
Operating Environment |
-10 to 50℃ |
Note |
*The K1 Max is currently compatible with Gateron/Keychron low-profile mechanical switches only, as QMK does NOT support low-profile optical switches. |
