Description
SPECIFICATIONS:
Number of Keys |
84 (75%) |
Switches |
Keychron low-profile mechanical - Brown |
Switch Face |
North-facing |
Number of Multimedia Keys |
12 |
Frame Material |
ABS+Aluminum frame |
Keycap Material |
Shine-through ABS |
Layout |
ANSI |
Polling Rate (Wired Mode) |
1000Hz |
Polling Rate (Wireless Mode) |
90Hz |
N-Key Rollover (NKRO) |
Yes for both wireless and wired modes |
Backlit |
White Backlight |
Battery |
1550 mAh rechargeable li-polymer battery |
Connection |
Bluetooth and Type-C cable |
Bluetooth version |
5.2 |
Bluetooth Device Name |
Keychron K3 Version 3 |
Compatible System |
macOS/Windows/Linux |
Dimension |
306 x 116 mm (12.04 x 4.56") |
Weight |
540 g / 1.19 lbs |
Height without keycap (front) |
9 mm (0.35") |
Height without keycap (rear) |
14 mm (0.55") |
Height incl. keycap (front) |
19 mm (0.75") |
Height incl. keycap (rear) |
23 mm (0.91") |
Typing Angle |
2.5º, 4.2º and 6.5º |
MCU |
Low-power ARM Cortex-M3 32-bit WB32F3G71RCT6 (256KB Flash) |
Operating Environment |
-10 to 50℃ |
Note |
*The K3 Version 3is currently compatible with Keychron low-profile mechanical switches only, as QMK does NOT support low-profile optical switches. |
