Description
SPECIFICATIONS:
Width |
145 mm |
Length |
327.5 mm |
Front Height |
22.6 mm (without keycaps) |
Back Height |
35.8 mm (without keycaps) |
Feet Height |
2.4 mm |
Angle |
5.2° |
Weight |
1724 g ± 10 g (Fully Assembled version) |
Body Material |
Aluminum |
Plate Material |
PC |
Keycap |
KSA double-shot PBT keycaps, not shine-through (Fully Assembled version) |
Switch |
Gateron Jupiter (Fully Assembled version) - Brown |
Stabilizer |
Screw-in PCB stabilizer |
Backlight |
South-facing RGB LED |
Hot-swappable |
Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc. |
MCU |
ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
Polling Rate |
1000 Hz (2.4 GHz & wired) / 90 Hz (Bluetooth) |
N-Key Rollover (NKRO) |
Yes for both wireless and wired modes |
Battery |
4000 mAh Rechargeable li-polymer battery |
Wireless Working Time (Backlit off) |
Up to 180 hours (Lab test result may vary by actual use) |
Wireless Working Time (RGB) |
Up to 100 hours (Lowest brightness) |
Bluetooth Version |
5.1 |
Compatible System |
macOS/Windows/Linux |
Connectivity |
2.4 GHz / Bluetooth / Type-C wired |
Bluetooth Device Name |
Keychron Q1 Max |
Operating Environment |
-10 to 50℃ |
