Description
SPECIFICATIONS:
Width |
148.9 mm |
Length |
368.7 mm |
Front Height |
22.04 mm (without keycaps) |
Back Height |
30.05 mm (without keycaps) |
Feet Height |
2 mm |
Angle |
3.5° / 7.26° / 9.69° |
Weight |
696 ± 10 g (Fully Assembled Version) |
Body Material |
ABS Plastic |
Plate Material |
PC |
Keycaps (Fully Assembled Version) |
Double-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape) |
Switches |
Gateron Jupiter (Fully Assembled Version) - Brown |
Hot-swappable |
Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX, Kailh, etc. |
Stabilizer |
Screw-in PCB stabs |
Cable |
Type-C cable + Type-A to Type-C adapter |
MCU |
ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
Charging Port |
USB Type-C |
Operating Environment |
-10℃ to 50℃ |
Polling Rate |
1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode) |
Mount Style |
Gasket Mount Design |
Backlight |
South-facing RGB LED |
N-Key Rollover (NKRO) |
Yes for both wireless and wired modes |
Compatible System |
Windows/macOS/Linux |
Bluetooth Version |
5.1 |
Bluetooth Device Name |
Keychron V3 Max |
Battery |
4000 mAh Rechargeable li-polymer battery |
Charging Time |
Around 5 hours |
Wireless Working Time (Backlit off) |
Up to 225 hours (Lab test result may vary by actual use) |
Wireless Working Time (RGB) |
Up to 100 hours (Lowest brightness) |
