Description
SPECIFICATIONS:
PERFORMANCE | |
Processor |
Intel® Core™ Ultra 5 125U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 4.3GHz, 12MB |
NPU |
Intel® AI Boost integrated in Intel Core™ Ultra processor |
Graphics |
Integrated Intel® Graphics |
Chipset |
Intel® SoC Platform |
Memory |
2x 8GB SO-DIMM DDR5-5600 |
Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable |
Max Memory |
Up to 64GB DDR5-5600 |
Storage |
256GB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
Storage Support |
Up to two drives, 2x M.2 SSD • M.2 2280 SSD up to 2TB |
Storage Slot |
Two M.2 2280 PCIe® 4.0 x4 slots |
Card Reader |
SD Card Reader |
Optical |
None |
Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec |
Speakers |
Stereo speakers, 2W x2, Dolby Audio™ |
Camera |
FHD 1080p + IR Hybrid with Privacy Shutter |
Microphone |
2x, Array |
Battery |
Integrated 45Wh |
Power Adapter |
65W USB-C® (3-pin) |
Special Features |
Modern Standby |
DESIGN | |
Display |
16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, 60Hz |
Touchscreen |
None |
Color Calibration |
None |
Keyboard |
Backlit, English |
Touchpad |
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
Case Color |
Arctic Grey |
Surface Treatment |
Anodizing Sandblasting |
Case Material |
Aluminium (Top), PC-ABS (Bottom) |
Dimensions (WxDxH) |
356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches) |
Weight |
Starting at 1.7 kg (3.75 lbs) |
SOFTWARE | |
Operating System |
Windows® 11 Pro, English |
Bundled Software |
Office Trial |
CONNECTIVITY | |
Ethernet |
100/1000M (RJ-45) |
WLAN + Bluetooth |
Wi-Fi® 6E, 802.11ax 2x2 + BT5.3 |
Standard Ports |
1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.1 and DisplayPort™ 1.4 1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.1 and DisplayPort™ 2.1 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) 1x SD card reader |
Docking |
Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for ThinkBook 16 G7 IML |
Security Chip |
Firmware TPM 2.0 Enabled |
Fingerprint Reader |
Touch Style, Match-on-Chip, Integrated in Power Button |
Physical Locks |
Kensington® Nano Security Slot™, 2.5 x 6 mm |
Other Security |
IR camera for Windows® Hello (facial recognition) Camera privacy shutter |
MANAGEABILITY | |
System Management |
Non-vPro® |
ACCESSORIES | |
Bundled Accessories |
None |
CERTIFICATIONS | |
Green Certifications |
ENERGY STAR® 8.0 EPEAT™ Gold Registered ErP Lot 6 ErP Lot 26 RoHS compliant TCO Certified 9.0 |
Other Certifications |
TÜV Rheinland® Low Blue Light (Software Solution) |
Mil-Spec Test |
MIL-STD-810H military test passed |
