Description
SPECIFICATIONS:
PERFORMANCE | |
Processor |
Intel® Core™ i7-13700, 16C (8P + 8E) / 24T, Max Turbo up to 5.2GHz, P-core 2.1 / 5.1GHz, E-core 1.5 / 4.1GHz, 30MB |
Graphics |
Integrated Intel® UHD Graphics 770 |
Chipset |
Intel® B660 Chipset |
Memory |
2x 8GB UDIMM DDR4-3200 |
Memory Slots |
Two DDR4 UDIMM slots, dual-channel capable |
Max Memory |
Up to 64GB DDR4-3200 |
Storage |
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
Storage Support |
Up to two drives, 1x 3.5" HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • M.2 SSD up to 1TB |
Card Reader |
None |
Optical |
None |
Audio Chip |
High Definition (HD) Audio, Realtek® ALC623-CG codec |
Speakers |
1Wx1 |
Power Supply |
260W 90% |
DESIGN | |
Keyboard |
USB Traditional Keyboard, Black, English |
Mouse |
USB Calliope Mouse, Black |
Expansion Slots |
One PCIe® 4.0 x16, low-profie (length < 167.65mm, height < 68.90mm) One PCIe® 3.0 x1, low-profie (length < 167.65mm, height < 68.90mm) Two M.2 slots (one for WLAN, one for SSD) |
Case Color |
Black |
Stand |
None |
Pen |
Pen Not Supported |
Form Factor |
SFF (7.4L) |
Dimensions (WxDxH) |
100 x 308 x 274.8 mm (3.9 x 12.1 x 10.8 inches) |
Weight |
Around 4.5 kg (9.9 lbs) |
CONNECTIVITY | |
Ethernet |
Integrated 100/1000M |
WLAN + Bluetooth |
None |
WWAN |
Non-WWAN |
Front Ports |
1x USB-C® 3.2 Gen 1 (support data transfer and 5V@3A charging) 2x USB 3.2 Gen 1 1x headphone / microphone combo jack (3.5mm) 1x microphone (3.5mm) |
Rear Ports |
2x USB 2.0 2x USB 3.2 Gen 1 (one supports Smart Power On) 1x HDMI® 2.1 TMDS 1x DisplayPort™ 1.4 1x VGA 1x Ethernet (RJ-45) 1x line-out (3.5mm) |
Optional Rear Ports (configured) |
None |
Monitor Cable |
None |
SECURITY & PRIVACY | |
Security Chip |
Discrete TPM 2.0, TCG certified |
Fingerprint Reader |
No fingerprint reader |
Physical Locks |
Kensington® Security Slot™, 3 x 7 mm Padlock Loop |
Smart Cable Clip |
None |
Chassis Intrusion Switch |
None |
MANAGEABILITY | |
System Management |
Non-vPro® |
CERTIFICATIONS | |
Green Certifications |
ENERGY STAR® 8.0 EPEAT™ Silver Registered ErP Lot 3 RoHS compliant TCO Certified |
SOFTWARE | |
Operating System |
Windows® 11 Pro, English |
